Oven for making thermal bonded nonwovens

Thermobonding oven with double layer conveyor utilizes the process of hot air penetration to heat fiber webs containing low-melting point fibers, achieving bonding and reinforcement for the web formation.

Working width: 2300mm~4000mm
Available products weight: 100~600 GSM
Heating area: 6 – 10 meters (customization)
Application

Thermobonding oven with double layer conveyor is used in nonwoven production lines and is particularly suitable for producing various high GSM and high-density products.

Specifications
Working width 2300mm~4000mm
Available products weight 100~600 GSM
Optional Heating method Boiler with thermal oil
Burner (gas, diesel, LPG etc)
Electrical radiator
Structure features Single floor ; Double conveyor
Heating area 6 – 10 meters (customization)
Cooling area 2 meters (customization)
Features
  • Thermobonding oven comes with a single-layer structure with two separate upper and lower hot air channels.
  • Circular airflow allows for efficient and uniform heating, resulting in excellent product quality.
  • Functions include automatic and precise temperature control, independently adjustable air volume and heating power.
  • Multiple insulation design helps in energy saving.
  • Optional heating methods are burner, boiler, electric heating.
