5083 Aluminum Alloy
Request a Quote
5083 aluminum sheets/plates available size range
- Thickness: 0.2-200mm
- Width: 30-2500mm
- Length: 500-13000mm
- Thickness: 0.2-6.35mm
- Width: 500-2500mm
Application
5083 aluminum alloy is suited for shipbuilding, fireproof pressure vessels, automotive and aircraft welded plates, vehicle bodies, tipper trucks bodies, mine skips & cages, missile parts, armored car, etc.
Aluminum alloy state, size and mechanical propertiesAlloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
Chinese standard | Value | ||||
5083 | O | >3.0-6.0 | 275-360 | 275-350 | ≥15 |
>6.0-12.5 | ≥16 | ||||
>12.5-50.0 | ≥15 | ||||
>50.0-80.0 | 270-345 | 270-345 | ≥14 | ||
H32 | >3.0-6.0 | 305-380 | 305-380 | ≥8 | |
H34 | >3.0-6.0 | 340-400 | 340-400 | ≥7 | |
H112 | >6.0-12.5 | ≥275 | ≥275 | ≥12 | |
>12.5-40.0 | ≥10 | ||||
>40.0-50.0 | ≥270 | ≥270 | ≥10 |
