PVT Series Vertical Temperature Test Chamber

Request a Quote

Website: http://testchamber-en.com/1-5-vertical-temperature-test-chamber.html

Space-saving upright test chamber with large processing capacity for high temperature testing applications

This upright chamber saves floor space while offering large capacity for high-temperature tests up to 200 °C. It features dual side cable ports, a precise touchscreen controller with fixed and programmable modes, vertical airflow for uniform heating, and durable insulation to maintain stable conditions. Ideal for evaluating electronics, coatings, and materials under consistent thermal stress.

Standard Configuration

3 sets of specimen racks
2 cable ports (Ø50 mm)
1 vent port
1 terminal block for controlling specimen power supply

Features

Space-saving vertical design with cable ports on both sides for easy connections
Touchscreen controller offering precise temperature control and flexible operation modes
Top and bottom airflow system to keep heat distribution even
Well-insulated chamber walls that help maintain stable internal temperatures
Suitable for testing needs up to 200 °C across electronics, coatings, and other materials

Technical Parameters

Model		PV221T	PV331T
Chamber volume (L)		324	768
Performance	Temperature range	(Ambient temperature 20)℃～200℃
	Temperature fluctuation	≤100℃: 0.4℃ ≤200℃: 0.8℃
	Temperature deviation	±2.0℃
	Temperature rise rate	(Ambient temperature 20)℃→200℃: ≤40min	(Ambient temperature 20)℃→200℃: ≤60min
Internal dimensions (mm)		W610×H900×D600	W830×H1200×D800
External dimensions (without protrusion) (mm)		W770×H1500×D925	W1030×H1800×D1145
Power supply		220V (single phase protective grounding wire)	380V (three phase four wire protective grounding wire)

Performance measured at 25 °C ambient temperature, with the chamber empty and no air exchange during operation.
