2-Roll Calender
Request a Quote
Professional footwear machinery manufacturer and complete footwear manufacturing solution provider
The 2-Roll Calender is used to calendar (or roll) the rubber into sheet form. The rubber material is fed into the machine and then pulled into the roller gap by frictional force and pressed into rubber sheet by the two rollers.
Features
- The two adjacent rollers rotate relative to each other at the same speed to form uniform rubber sheets.
- By calendaring between the two rollers, multilayer rubber sheet can be pressed.
- In production, the rubber material can be extruded onto the steel cord fabric to produce patterns on the surface of the rubber sheet.
Specification
Calender
Roller size：170*600 mm
Rolling thickness：0.2-8 mm
Power:4 kw
Linear speed：1.4-14.3 m/min
Overall size：1800*850*1100 mm
Weight:1100 kg
Conveyor
Conveyor width：600 mm
Power:0.75 kw
Overall size：3900*760*720 mm
Weight:720 kg
