We can get your roll form line custom manufactured according to your desired pipe types. With the rich experience and skills in designing and manufacturing roll forming machines for various pipes with complex cross-section, we are capable providing fully automatic pipe production line with custom-tailored configurations including hole punching, welding, polishing and more processes adapted to the requirements of profiles, satisfying your individual production demands of multiple specifications or length adjustment.

Easy-to-use touch screen interface allows user to simply input data and product output setting without mechanical adjustments. And all the key electrical components including PLC and inverter are from German and Japanese well-known brands, ensuring long-lasting operation with high stability.

Lay out
Technical Data
Forming material 0.4~3mm cold/hot-rolled and aluminum alloy metal strip
Forming passes 10~36
Production speed 6~35m/min
Cut off Hydraulic/saw/grinding wheel/pneumatic (selectable upon request)
Processing quality Straightness: L≤2000mm, curvature≤2mm; deflection≤2º
No surface wrinkles, bumps, scratches or other defects
Cross-section size and hole position meet customer’s requirements or national standards
Power 380V±10% / 50Hz / 15KW
