View All: http://wastewater-plant.com/1-7-chlorine-dioxide-generator.html

This chlorine dioxide generator uses sodium chlorate and hydrochloric acid (31%) as raw materials to produce a compound disinfectant that is mainly composed of chlorine dioxide and supplemented by chlorine gas which can be widely applied to disinfection treatment of drinking water, secondary water supply, swimming pool water and hospital sewage.

Parameter

Model	Yield of chlorine dioxide (g/h)	Pressure (MPa)	DN1(mm)	DN2(mm)	Power (kw)
BT-50	50	≥0.20	25	32	1.0
BT-100	100	≥0.20	25	32	1.0
BT-200	200	≥0.20	25	32	1.0
BT-300	300	≥0.20	25	32	1.0
BT-500	500	≥0.20	25	32	1.0
BT--800	800	≥0.25	25	32	1.0
BT-1000	1000	≥0.25	32	40	2.0
BT-2000	2000	≥0.25	32	40	2.0
BT-3000	3000	≥0.30	32	40	2.0
BT-4000	4000	≥0.30	40	50	2.0
BT-5000	5000	≥0.30	40	50	2.0
BT-6000	6000	≥0.30	40	50	3.0
BT-7000	7000	≥0.30	40	50	3.0
BT-10000	10000	≥0.30	50	60	3.0
BT-15000	15000	≥0.30	50	60	3.0
BT-20000	20000	≥0.30	50	60	3.0

Details

The NEWDOSE metering pump uses an anti-corrosive plastic shell, whose protection level is IP65, thus, prolonging the service time.

The microcomputer control instrument of chlorine dioxide generator can display the display screen, and the automation degree of which is high.
