CNC Wood Cutting Machine
Request a Quote
- The milling cutter can cut any angle to make any shape of wood workpieces.
- The finished product surface is flat and only needs to be slightly sanded, saving the material and processing time.
- The wood cutting machine will run automatically without professional manual operation, as long as the milling cutter is programmed in advance.
- The CAD drawing software is easy to learn and use.
- With streamlined processing procedures, the cutting machine is suitable to process materials for wood furniture, handicrafts and toys.
| Model | MDDX-1200 | MDDX-2500 |
| Max. processing dimensions | 1350*1200*140mm | 1350*2500*140mm |
| Processing speed | 0-5m/min | 0-5m/min |
| Idling speed | 20m/min | 20m/min |
| Spindle speed | 9000-18000r/min | 9000-18000r/min |
| Spindle power | 7.5kW*2pcs | 7.5kW*2pcs |
| Servo motor power | 1kW*2pcs, 0.75kW*1pcs | 1kW*2pcs, 0.75kW*1pcs |
| Mounting dimensions | 1900*2650*1650mm | 3250*2650*1650mm |
| Net weight | 2000kg | 3000kg |
