EDS-A200 VFD for Single Phase Motor

Request a Quote

View All: http://inverteracdrive.com/1-8-motor-frequency-inverter/index.html

Features
1. Special design for single phase induction motor with start-up capacitor
2. Used for pump and fan motor applications
3. Space voltage vector SVPWM control
4. Independent 8 step speed control, control is more accurate and convenient
5. Excellent power supply adaptability, can be applied to rural power grids with large fluctuation
6. Panel control, terminal control and other methods controls can be realized
7. Equipped with large capacity capacitors, can store certain slowly-rising energy.
8. Built-in simple PLC function, traverse function for more extensive adaptability.
9. Containing failure memory function, which simplifies troubleshooting tasks
10. MODBUS RTU communication is available

Product Model

Inverter type	Rated power	Rated output current(A)	Adapted motor(KW)
EDS-A200-2S0002	0.6	1.6	0.2
EDS-A200-2S0004	1.1	3	0.4
EDS-A200-2S0007	1.8	4.7	0.75
EDS-A200-2S0015	2.8	7.5	1.5
EDS-A200-2S0022	3.8	10	2.2
EDS-A200-2S0037	5.6	17	3.7

Parameters

Item			Item description
Input	Rating volt., frequency		Single phase 220V, 50Hz/60Hz
	Allowed work volt. range		Single phase voltage: 200V~260V
Output	Voltage		220V grade: 0~220V(no more than input volt.)
	Frequency		0Hz-400Hz
	Over loading capacity		150% of rating current for1 minute, 200% of rating current for 0.5 second;
Control performance	Control mode		Optimum space voltage vector SVPWM constant volt. Frequency ratio V/F control
	Speed regulation range		1:100
	Start-up torque		100% of rating torque at low frequency
	Running speed stable state precision		≤±0.5% of rating synchronous speed
	Frequency precision		Digital setting: max. frequency×±0.01%; analog setting: max.frequency×±0.5%
	Frequency resolution	Analog setting	0.1% of max. frequency-+96
		Digital setting	0.01Hz
		Exterior pulse	0.5% of max. frequency
	Torque boost		Automatic torque boost, manual torque boost 0.1%~20.0%
	V/F curve (volt. frequency characteristic)		Set rating frequency randomly at range of 5~400Hz, can choose constant torque, degressive torque 1, degressive torque 2, degressive torque3 intotal 4 kinds of curve
	Accelerating decelerating curve		2 modes: straight line accelerating decelerating and S curve accelerating decelerating; 7 kinds of accelerating decelerating time (unit: minute/second can be optioned), max. time 6000 minutes.
	brake	Power consumption brake	Exterior brake resistance
		DC brake	Optional start-up and stop, action frequency 0~15Hz, action volt. 0~15%, action time 0~20.0 s
	Jog		Jog frequency range: 0.50Hz~50.00Hz; jog accelerating decelerating time 0.1~60.0s can be set
	Multi-section speed running		Realized by interior PLC or control terminal
	Interior PID controller		Be convenient to make closed-loop system
	Automatic energy save running		Optimize V/F curve automatically based on the load to realize power save running
	Automatic volt. regulation (AVR)		Can keep constant output volt. When power source voltage varies.
	Automatic current limiting		Limit running current automatically to avoid frequent over-current which will cause trip
Running function	Running order specified channel		Key pad specified, control terminal specified, serial port specified
	Running frequency specified channel		Digital provision, analog provision, impulse provision, serial port provision, combined provision, can be switched at any time by kinds of method
	Pulse output channel		Impulse square wave signal output of 0~20KHz, can realize output of physical parameter such as setting frequency, output frequency etc.
	Analog output channel		1 channel of analog signal output, AO channel can be 4~20mA or 0~10V; through it the inverter can realize output of physical parameter such as setting frequency, output frequency etc.
keypad	LED display		Can display setting frequency, output frequency, output voltage, output current etc. in total 14 kinds of parameter
	Lock the button		Lock all or part of the buttons (analog potentiometer can't be locked)
Protection function			Over-current protection, over-voltage protection, lack-voltage protection, over-heat protection, over-load protection, missing phase protection (in option) etc.
Fitting parts			brake subassembly, remote-control keypad, connecting cable for remote-control keypad etc.
ambient	Use ambient		Indoor, not bare to sunlight, no dust, no corrosive gas, no flammable gas, no oil fog, no vapor, no water drop or salt etc.
	Altitude		Lower than1000m
	Ambient temperature		-10ºC~+40ºC(under ambient temperature 40ºC ~50ºC, please reduce the volume or strengthen heat sink)
	Ambient humidity		Smaller than 95%RH, no condensation water
	Vibration		Smaller than5.9m/s²(0.6g)
	Storage temperature		-40ºC~+70ºC
Configuration	Defending grade		IP20
	Cooling mode		By fan with automatic temperature control
Mounting mode			Wall hanging
