Cable Preparation Machine
Our cable preparation machine is suitable for data cable production with functions of wire cutting, jacket stripping, copper foil assembling and automatic cable collection.
- Wire cutting
- Jacket stripping
- Braid brushing
- Braid cutting
- Copper foil tape wrapping
- Laser cutting of aluminum foil/Mylar
- Removal of aluminum foil/Mylar
- Automatic cable collection
- Power supply: 220V, 50HZ
- Power: 2.5KW
- Air pressure: 0.6-0.8Mpa
- Dimension: 2800L*700W* 1650H (mm)
- Production output: 1000Pcs/H
- Applicable wire diameter: φ3.0-5.0mm
- Wire cutting length: 400-2300mm
- Jacket stripping length: 10-25mm
- Copper foil size: 3mm-6mm
XIANGYE provides a broad range of cable processing machinery including cable preparation machine, automatic soldering machine, cable tinplate assembly machine, automatic electrical testing and molding machine, automated barcode scanning system and cable packaging machine. We strive to solve your specific needs by design and custom-manufacture professional automated equipment suitable to your cable applications in various industries. We pride ourselves in our knowledge and expertise in manufacturing cable machinery for a variety of products, such as USB Type C 2.0 cable, Type C 3.0 cable, Type C 3.1 cable, GEN 2 cable, USB Type C 3.1 GEN2 8 coaxial cable, Apple C48 cable, Apple C94 cable, Mini-SAS cable, LVDS cable, SFP cable and FFC cable.
