High Frequency RFID Tag
Request a Quote
RFID asset tracking system, RFID solutions
YUANBEN’s RFT-323 high-frequency RFID landmark label (RFID tag) uses a self-adhesive 3M tape as the installation material and PBT plastic as the packaging material. It features a solid round sheet structure, excellent compressive strength and easy installation.
Features
- Sole ID tag ensures non-duplication and safety.
- The tag can be written or read repeatedly over 100K times.
- Anti-collision function: even though multiple tags are used at the same time, this RFID tag can be detected accurately to ensure the correct data exchange.
- PBT material package, 3M adhesive tape installation and single mounting.
- Ideal for AGV address management and controlling.
Technical Parameters
Working Frequency | 13.56MHz |
Reading Distance | 70-90mm |
Communication Protocol | ISO15693 |
Tag Type | I-CODE |
Tag Memory | 1 Kbit (be capable of reading or writing) |
Baud Rate | 53Kbps |
Data Protection Mode | Write lock |
Data Storage | Over 10 years |
Installation | 3M adhesive tape |
Color | white |
Dimension | 30mm•1mm or required |
Weight | 1g |
Housing Material | ABS, PST, PPS or required |
Working Temperature | -20℃- 70℃ |
Storage Temperature | -20℃- 85℃ |
Working Humidity | < 95% RH |
