High Frequency Transformer (EPC Core)
Request a Quote
Southern Group provided EPC power transformer has a rated powerranging from 1.0VA to 24VA. It is widely used in TV, display, switching powersupply, etc. And we can customize the size based on customers’ demands. Thefollowing sizes are only for reference.
Parameters| Type | Pin Number | Dimensions (mm) | ||||
| A | B | C | D | E | ||
| EPC-13 | 4+4 | 6 | 17 | 20 | 3.0 | 13.5 |
| EPC-15 | 5+5 | 7.3 | 18.2 | 21.35 | 2.5 | 15 |
| EPC-19 | 5+5 | 7.5 | 19.3 | 22.6 | 3.0 | 16.7 |
| EPC-19 | 5+6 | 9.4 | 25.3 | 27.7 | 3.75 | 21.7 |
| EPC-20 | 6+6 | 9.7 | 24 | 26.8 | 3 | 20 |
| EPC-25 | 5+5 | 13.4 | 29.7 | 35.4 | 5 | 25 |
| EPC-30 | 5+5 | 12.6 | 29.7 | 31.5 | 5 | 25 |
| EPC-35 | 6+6 | 12.6 | 31.6 | 35.3 | 5 | 30 |
