Industrial Blower

Oil-free screw blowers are available for flow rates from 239 to 8605m3/hr, and operating pressure ranging between 0.3bar and 1.2bar. This screw blower can reduce energy costs up to 35-40% compared to roots blower. It featured by quiet operation, driven by a variable speed, permanent magnet synchronous motor, and controlled by microprocessor controller and remote control system.

  • Free air delivery

    0.81-22m³/min

  • Power

    7.5-132kW

  • Discharge pressure

    0.8-1.25MPa

Features
  • High stability, can meet the demands of continuous 24-hour use;
  • The internal compression process provides lower energy consumption compared to roots blower;
  • Variable speed drive provides higher energy efficiency;
  • Touch screen control panel allows remote control, with multiple protection functions;
  • High efficiency oil-free screw rotor profiles greatly reduce dynamic flow losses while improving efficiency; 6.Silencer ensures low noise emissions, delivering extremely quiet operation;
  • Complete control system helps achieve remote control and unmanned operation;
  • Used for wastewater aeration, backflushing, flue gas desulphurization (oxidation), fluidization and homogenization, etc.;
Technical Data
Rotation Speed (r/min) Discharge Pressure (kPa) 70 80 90 100 110 120 Starting Method Outlet Diameter Dimensions (mm)
1500 Flow (m³/min) 9.8 9.7 9.5 9.4 9.3 9.2 Permanent magnet frequency conversion DN200 2650×1300×1830
Motor Power (kW) 18.5 22 22 22 30 30
