Uses: It used to compress the copper and aluminum terminals

Notes: Packaged in plastic box

Item Number 16208 16208A 16209 16209A
Model BZ-300 BZ-400 ECTX-300 ECTX-400
Max Compression(kN) 60 120 60 120
Stroke(mm) 17 42 17 42
Compress range Copper Terminal 16-300mm² Copper Terminal 16-400mm² Copper Terminal 50-300mm² Copper Terminal 50-400mm²
Aluminum Terminal 10-240mm² Aluminum Terminal 10-300mm² Aluminum Terminal 35-240mm² Aluminum Terminal 35-300mm²
Battery 18V3Ah 18V3Ah 18V3Ah 18V3Ah
Compression Die Size Hexagon Die: 16, 25, 35, 50, 70, 95, 120, 150, 15, 240, 300 Hexagon Die:50, 70, 95, 120, 150, 185, 240, 300, 400 Hexagon Die: 50, 70, 95, 120, 150, 15, 240, 300 Hexagon Die: 50, 70, 95, 120, 150, 185, 240, 300, 400
