Integrated Test Chamber
The integrated test chamber is a multifunctional system that simulates various environmental conditions, including temperature changes, humidity, low air pressure, and mechanical vibrations. It enables precise assessments of product durability and performance in demanding conditions. Users can customize test cycles by combining temperature, humidity, low-pressure environments, and vibrations (sinusoidal or random) to replicate real-world stress factors. This testing system ensures reliable evaluation of material properties, component integrity, and overall product lifespan under extreme conditions.
The integrated test chamber meets the following international and military testing standards:
- GB2423.1-2008 (IEC 68-2-1)
- GB2423.2-2008 (IEC 68-2-2)
- GB2423.3-2006 (IEC 68-2-3)
- GB2423.4-2008 (IEC 68-2-30)
- GB2423.22-2008 (IEC 68-2-14)
- GJB150.3A-2009 (MIL-STD-810D)
- GJB150.4A-2009 (MIL-STD-810D)
- GJB150.9A-2009 (MIL-STD-810D)
| Model | Temp. Range | Humidity Range | Cooling method | Volume | External Dimensions | Shaker Table and Chamber Size |
| -40℃ to 150℃ | 20% to 98% RH | Water/ Air | 1.2 m³ | 4330*2000*1650 mm | 600*600 mm | |
| -70℃ to 150℃ | 20% to 98% RH | Water/ Air | 1.2 m³ | 4330*2000*1650 mm | 600*600 mm | |
| -40℃ to 150℃ | 20% to 98% RH | Water/ Air | 2.0 m³ | 4550*2120*1800 mm | 800*800 mm | |
| -70℃ to 150℃ | 20% to 98% RH | Water/ Air | 2.0 m³ | 4550*2120*1800 mm | 800*800 mm | |
| -40℃ to 150℃ | 20% to 98% RH | Water/ Air | 3.0 m³ | 5350*2300*2000 mm | 1000*1000 mm | |
| -70℃ to 150℃ | 20% to 98% RH | Water/ Air | 3.0 m³ | 5350*2300*2000 mm | 1000*1000 mm | |
| -40℃ to 150℃ | 20% to 98% RH | Water/ Air | 4.6 m³ | 5350*2000*2160 mm | 1200*1200 mm | |
| -70℃ to 150℃ | 20% to 98% RH | Water/ Air | 4.6 m³ | 5350*2000*2160 mm | 1200*1200 mm |
- Automotive: Sensors, controllers, and various automotive components.
- Electronics & Appliances: Mobile phones, computers, and household appliances such as refrigerators, washing machines, and air conditioners.
- Aerospace: Aircraft, satellites, and related components and materials.
Providing Highly Reliable Testing Equipment and a Full Range of Solutions. Our technical team are always here to help.
