Beer fermentation vessels are used as fermentation and storage tanks for alcoholic beverages and dairy products. These beer fermenters are quite useful in a wide variety of applications in food, beverage, dairy product, pharmaceuticals, chemical engineering, pharmaceutical, and bioengineering industry.
Volume (L) | Diameter (mm) | Height (mm) | Conical Bottom Head |
200 | 600 | 700 | 60° conical bottom |
300 | 700 | 700 | |
400 | 800 | 700 | |
500 | 900 | 700 | |
1000 | 1000 | 1000 | |
2000 | 1200 | 1220 | |
3000 | 1300 | 1500 | |
4000 | 1600 | 1800 | |
5000 | 1700 | 2000 |
Features
- Our beer fermentation vessels are available in a very wide range of volumes from 100L to 5000L. We can design and manufacture custom beer fermenter as your request.
- The bottom is designed with conical shape, with cooling jacket. The cooling jacket is coated with an insulation layer of polyurethane foam (cold insulation).
- With quick change chuck interface, the inner body is made from 304 or 316L stainless steel, with the mirror polished internal surface of Ra≤0.28μm-0.6μm. The external surface can be processed with your specific requirements such as polishing, wiredrawing, and sandblasting.
