Our mobile shelving system is a kind of intelligent light shelving system, incorporated with manual, electric and computerized operations. It can be controlled in the long distance with three independent ways of transmission. This type of mobile shelving system have the function of triple safe protection, automatic positioning and remote control.

Features:
  • Structure: advanced integrated mechanism of transmission with stability and convenience
  • High intelligentization: automatic generation of identification codes, orderly management of materials and voice prompt for exceptional conditions. The whole archives management is simple, accurate, effecient and safe.
  • Safety: low voltage of the control segment. The control panel: 5V, 12V DC power; The electromagnetic clutch: 24V DC power; The integrated motor system: 36V DC power. Provide full aisle protection by infrared.
Standard specifications:

Height 2300mm / Pithch 900mm / Width 500mm
6 levels, 330mm level distance, bearing-load capacity of 80kg per level
Components: 20mm×20mm steel rails, 3.0mm baseplates, 1.0mm clapboards, 1.2mm side panels, shock-resistant devices, anti-tilt devices, etc

1. Simple and accurate operation:

Double sided control panels help you simplify the process. Start buttons are installed on each level for opening the mobile shelving system. Manual operation is availble in case of power failure. The software developed by ourselves can improve the archives management, automatic opening for your expected shelf.

2. Triple safe protection:

(1)Light: professional lights for preventing workers from accidental injury. When the protection system starts, any shelf should not open. (2)Infrared: infrared systems start when the shelf opens, to ensure operator's safety inside.(3)Electromagnet: the electromagnetic induction system for preventing workers from accidental injury.

3. Automatic positioning

The LED system helps the archives storage. The light can show the aim position you input on the computer. It is a safe, convenient and simple way of handling enormous data.

4. File protection:

(1) Thermo-hygrometer
(2) Intelligent ventilation system
Ventilation button designed for the proper environment.

5. Remote control:

It is convenient to open and close the shelf via computer. The supervisory computer can be installed at the place whevever you want, operated with password permission.

Manufacturing techniques for surface:
  • Oil and rust removed
  • Phosphating
  • Phosphate coating

Our mobile shelving use cold-rolled steel and experience various procedures such as phosphating. It is anti-rust, anti-dust, easy-to-assemble, flexible with a fashion style. Each panel can be adjusted to your expectation. Besides, different protection systems maxmize the safety of every worker.
