Medium / Heavy Duty Gravity Conveyor Roller
Request a Quote
AL1300
Non-powered rollers for gravity roller conveyor
Medium/ heavy duty gravity conveyor roller has a full range of diameters, a large load capacity, and a metal stamping bearing plate with strong pressure resistance. As a typical series of non-powered rollers, its application range is very wide.
Applications
Medium/ heavy duty gravity conveyor roller is particularly suitable for transferring containers and cartons, such as airport baggage handling, logistics distribution centers, and so on.
Features
- Utilizes metal stamping bearing plate
- Uses precision deep groove ball bearings with a large load capacity
- Fully conductive and anti-static design
- Temperature range: -20℃ to 80℃
Technical Data
| Tube Diameter (D) | Tube Thickness (T) | Axis Diameter (d) | Tube Material | ||
| Galvanized Steel | Stainless Steel | Aluminum Alloy | |||
| 38 | 1.2/1.5 | 12 | √ | √ | |
| 50 | 1.5 | 12/15 | √ | √ | √ |
| 50 | 2 | 12/15 | √ | √ | |
| 50 | 2.5 | 12/15 | √ | √ | |
| 50 | 3 | 12/15 | √ | √ | |
| 60 | 1.5/2 | 12/15/20 | √ | √ | √ |
| 60 | 3 | 12/15/20 | √ | √ | |
| 60 | 3.75 | 15/17/20 | √ | √ | |
| 76 | 2/3/3.5/3.75 | 15/20 | √ | √ | |
| 89 | 3/3.5 | 20 | √ | √ | |
| 108 | 3/3.5 | 20 | √ | √ | |
