Commercial and industrial water filtration system for separating and removing suspended solids and colloids from water
Designed to handle demanding water purification tasks, the ultrafiltration membrane system is built with multiple components, including a lift pump, self-cleaning filter, ultrafiltration membranes, backwash pump, blower, ultrafiltration water tank, valves, instruments, and dosing pumps. The ultrafiltration membranes feature pore sizes between 0.001 to 0.02 microns. This allows small molecules and dissolved salts to pass through while effectively capturing colloids, microorganisms, and large organic molecules. This ensures that the water produced is exceptionally clean, making it ideal for applications requiring high purity.
Applications
The versatility of the Ultrafiltration Membrane System makes it suitable for a wide range of processes:
- Enhances the treatment and reuse of wastewater in industries such as power generation, steel production, petrochemicals, and food processing
- Serves as a crucial pre-treatment step in seawater desalination and reverse osmosis systems
- Ideal for purification, concentration, and separation processes in the food and biopharmaceutical industries, ensuring that the final products meet stringent purity standards
Specifications
| Average Pore Size | 0.01-0.03μm |
| Inside Diameter of Hollow Fiber Membrane | 0.7mm |
| Outside Diameter of Hollow Fiber Membrane | 1.3mm |
| Working Temperature | 5-40℃ |
| Operating pH Range | 2-12 |
| Max. Transmembrane Pressure Difference | 0.15MPa |
| Max. Feed Pressure | 0.3MPa |
| Max. Backwash Pressure | 0.2MPa |
| Backwash Time | 30-90s/20-60min |
