Spiral Degassing and Decontamination Device
Request a Quote
Water treatment device for gas water separation, sedimentation, and filtration
The spiral degassing and decontamination device is designed with a special spiral tube that creates a still area inside the unit. This still area allows particles of all sizes to settle at the bottom, where they are collected in a sediment chamber. Utilizing gas-water separation, sedimentation, and filtration principles, this device efficiently removes dissolved microbubbles and free gases from the water, ensuring cleaner and more efficient operation. The carbon steel housing adds to the device's longevity, enabling it to discharge contaminants effectively while the system is running.
Applications
Ideal for air conditioning cooling water systems and industrial circulating water systems, ensuring clean and efficient operation.
Features
- Significantly reduces system commissioning time after the first water injection, eliminating the need for additional air release valves
- Allows for contaminant removal while the system is in operation
Use Conditions
| System Water Quality | pH>6.5, Totla Hardness < 700mg/1(CaC03), Totla Hardness Total Alkalinity< 800(CaC03) |
| Water Temperature | < 90℃ (temperature of water passing water treatment system) |
| Water Pressure | < 1.0Mpa (custom requirements < 2.5Mpa ) |
| Concentration Rate | < 3.5 (for cooling water system) |
| Working Temperature | -40℃~55℃ |
| Humidity | < 90% (below 20℃) |
Model Options
| Model | Connection | Total Height (mm) | Body Diameter (mm) | External Diameter of Flange (mm) | Distance from Top to Inlet/Outlet (mm) | Total Width (mm) | Weight (kg) |
| DN 50 | 565 | 175 | 165 | 365 | 350 | 14.5 | |
| DN 65 | 565 | 175 | 185 | 365 | 350 | 14.5 | |
| DN 80 | 765 | 270 | 200 | 450 | 470 | 31.0 | |
| DN 100 | 765 | 270 | 220 | 450 | 470 | 33.5 | |
| DN 125 | 980 | 360 | 250 | 550 | 635 | 59.0 | |
| DN 150 | 980 | 360 | 285 | 550 | 635 | 63.0 | |
| DN 200 | 1193 | 450 | 340 | 708 | 774 | 115 | |
| DN 250 | 1577 | 600 | 406 | 892 | 990 | 215 | |
| DN 300 | 1742 | 600 | 460 | 1032 | 1006 | 255 | |
| DN 350 | 1986 | 800 | 580 | 1109 | 1214 | 490 | |
| DN 400 | 2159 | 800 | 508 | 1252 | 1220 | 545 | |
| DN 500 | 2590 | 1000 | 715 | 1470 | 1580 | 882 | |
| DN 600 | 3085 | 1200 | 840 | 1756 | 1870 | 1750 |
