Continuous Frozen Meat 3D Cutting Machine (Dicer/Slicer/Strip Cutter)
Request a Quote
Meat Processing Multifunctional meat cutting machine for continuously cutting frozen blocks of meat, poultry and fish into consistent cubes, slices or strips
Continuous frozen meat 3D cutting machine enables 25 kg blocks of meat to be processed directly into finished cubes, strips, or slices in a single continuous operation, without the need for intermediate transfer devices. It performs horizontal cutting, vertical cutting, and circular cutting in one integrated workflow.
-
- Sliced pork
-
- Pork strips
-
- Pork cubes
Key Parameters
| Model | TF3W |
| Power | 18 kW |
| Power supply | 3-phase 380 V, 50 Hz |
| Air source | 0.5 Mpa |
| Circular blade diameter | 200 mm |
| Max cube size with circular blade | 50 mm |
| Max loading size | 450 × 800 × 200 mm |
| Raw material cutting temperature | –10 °C to –3 °C |
| Production defrosting environment temperature | –6 °C to –3 °C |
| Optimal cutting temperature range | –6 °C to –5 °C |
| Cutting speed | 42-90 cuts/min |
| Control system | PLC touch screen with frequency converter |
| Feeding method | Continuous |
| Weight | 2500 kg |
| Lubrication method | Integrated grease nipples |
| Dimensions | 3800 × 1200 × 1940 mm |
Features
-
Equipped with a touch screen and PLC control system, with variable frequency speed adjustment to match the required cutting speed for different materials.
-
Upper and lower conveyor belts clamp and transport the product synchronously, while the upper pressing belt keeps full surface contact with the material at all times for stable feeding.
