Continuous Frozen Meat Dicer, Slicer & Strip Cutter
Designed to meet diverse processing requirements, continuous frozen meat dicer, slicer & strip cutter allows independent control of two cutting assemblies, enabling multiple functions such as slicing strip cutting and dicing within a single unit.
The entire machine is constructed from 304 stainless steel and food grade nonmetal materials in full compliance with HACCP standards. It is suitable for meat processing plants central kitchens and meal distribution facilities.
-
- Frozen pork belly cubes
-
- Frozen pork strips
-
- Frozen beef cubes
-
- Frozen pork slices
Key Parameters
| Model | HK-470A |
| Power | 9.12 kW |
| Power supply | 3 phase 380 V 50 Hz |
| Air source | 0.2 MPa |
| Max material width | 468 mm |
| Max material height | 50 mm |
| Circular blade diameter | 200 mm |
| Cutting temperature | –10°C to 3°C |
| Thawing environment temperature | –6°C to 3°C |
| Optimal cutting temperature | –6°C to –5°C |
| Cutting speed | 42-85 cuts/min |
| Control system | PLC / VFD |
| Feeding method | Continuous |
| Lubrication | Integrated grease nipples |
| Weight | 1500 kg |
| Dimensions | 2580 × 1130 × 1740 mm |
Features
-
Built entirely from 304 stainless steel, offering corrosion resistance, low maintenance costs, and long-term structural stability. Certified to international food-grade standards (China GB 4806.9), it resists fading and deformation during prolonged use.
-
A built-in protection system including a temperature sensor and overload protector automatically cuts power or reduces speed when the motor is overloaded or overheated preventing motor damage.
-
The conveyor belt is easy to remove withstands high temperatures and wear and has a long service life.
-
An emergency stop switch immediately halts operation ensuring reliable safety.
