2D Frozen Meat Dicer
Meat Processing Equipment
Industrial meat cube cutter for cutting frozen bone-in or boneless meat, poultry and fish into cubes
- Cutting Size 10-40mm
- Processing Capacity 300-1000 kilograms per hour
2D frozen meat dicers are built to efficiently cut frozen bone-in or boneless meats, poultry, fish, and seafood into uniform cubes. Designed to handle temperatures between -3°C and -6°C, these meat processing machines use adaptive pressing and feeding conveyor belts to ensure smooth and consistent material handling. Their modular feeding systems allow for easy disassembly, simplifying cleaning and maintenance routines. Constructed with 304 stainless steel, these dicers meet strict food hygiene standards and feature waterproof designs for thorough cleaning. This meat cube cutter is equipped with various safety elements including independent protective covers, safety switches, an automatic lubrication system, and an oil-level alarm. Customization options, such as PLC and touchscreen controls, provide added convenience for precise adjustments to cutting thickness.
Ideal for processing frozen meats and seafood into consistent cubes, 2D frozen meat dicers are ideal for food production lines, meat processing facilities, and central kitchens.
- Model: DRB-QK300
- Voltage: 380V, 50Hz
- Power: 3kW
- Processing capacity: 300-500kg/h
- Feeding size (W×H): 300×100mm
- Cutting size: 10/15/20/25/30/35mm (choose one size)
- Dimensions (L×W×H): 680×1000×1200mm
- Weight: 284kg
- Model: DRB-QK500
- Voltage: 380V, 50Hz
- Power: 4kW
- Processing capacity: 500-1000kg/h
- Feeding size (W×H): 500×100mm
- Cutting size: 10/15/20/25/30/35mm (choose one size)
- Dimensions (L×W×H): 880×1000×1200mm
- Weight: 342kg
- Model: DRB-QK300L
- Voltage: 380V, 50Hz
- Power: 3kW
- Processing capacity: 300-500kg/h
- Feeding size (W×H): 300×100mm
- Cutting size: 10-40mm (adjustable)
- Dimensions (L×W×H): 1460×700×1180mm
- Weight: 306kg
- Model: DRB-QK500L
- Voltage: 380V, 50Hz
- Power: 4kW
- Processing capacity: 500-1000kg/h
- Feeding size (W×H): 500×100mm
- Cutting size: 10-40mm (adjustable)
- Dimensions (L×W×H): 1470×895×1185mm
- Weight: 368kg
