Application
The CMM700-360 plastic thermoforming and thermoplastics machine, with a maximum formed area of 700 x 300mm, is primarily used for processing plastic sheets and the production of disposable plastic bowls, drinking cups, ice-cream cups, jelly cups and other packaging or containers. Primary materials used include PP, PE, PS, PET, HIPS, PVC and other degradable materials.

Production technique
This plastic thermoforming machine is made up of the sheet loader, main machine, winding frame, and electrical control cabinet.

The process includes:
Sheet loading → Heating → Stretch forming → Cutting → Finished product blowing

Technical parameter
Main Motor Power 7.5kw
Formed Area ≤700*300mm
Formed Speed ≤35time/min
Sheet Width ≤700mm(adjustable)
Sheet Thickness 0.2-2.5mm
Machine Power ≤100kw (the actual is about 60%)
Air Pressure ≤0.6-0.8Mpa
Gas Consumption 1.5-2.0m³/min
Water Consumption ≤0.5m³/24h
Size (L*W*H) 3.5*1.5*2.5m

Optional models
1. CMM 700-360A, formed depth ≤130mm
2. CMM 700-360B, formed depth ≤180mm

ELITE Plastics is manufacturing plastic forming and sheet extrusion equipment, such as sheet extrusion line for various plastic materials like PE, PPT, PS, PET, etc. and offers the custom thermoplastic machines and thermoforming equipment and other plastic thermoforming machines. With almost 20 years experiences of manufacturing plastic machines, ELITE Plastics can provide any client good plastic thermoplastic and extrusion machines.
