Home oxygenation system is oxygen control equipment to simulate sea-level. By adding oxygen of higher concentration into the tent or the room, we can bring any high altitude space back down to sea-level. This oxygen equipment can convert literally any size space to a high oxygen, seal-level environment. We can provide multiple control panels so that each room can be independently controlled.

Technical Parameters
Model JAY-10M JAY-20M JAY-40M JAY-60M
Flow Rate 0-10L 0-20L 0-40L 0-60L
Outlet Pressure 6-10Psi/20Psi (0.04-0.07Mpa/0.14Mpa)
Oxygen Concentration 93% (±3%)
Sound Level ≤52dB ≤55dB ≤58dB ≤60dB
Power Consumption ≤550W ≤1100W ≤2200W ≤3300W
Alarms Power failure alarm, high/low pressure alarm
Weight 30kg 95kg 160kg 245kg
Dimension 470*440*700mm 810*440*670mm 600*400*1380mm 760*540*1380mm 760*540*1960mm
    Features
  • 24/7 automatic monitoring of indoor oxygen concentration level
  • Automatically adjust the indoor oxygen concentration as different requirements
  • Increase users’ SPO2 level
  • Extend longevity of plateau people
  • Decrease susceptibility to altitude sickness and improve sleep quality
  • Speed up acclimatization process when arriving at altitude
  • Sealed tent available as optional, designed to create comfortable and oxygen-enriched environment, is simple and inexpensive
    Application
  • Who Can Benefit: This home oxygen system is ideal for residents who live in plateau area or those with high altitude homes or for hotels and resorts that cater to sea-level residents coming to high altitudes for skiing and other adventures.
  • What Spaces: For bedrooms, offices at hotels, resorts, military camp, government, schools in plateau area and some refined spaces such as sauna rooms in plain area.
  • Countries and Regions: Peru, Chile, Bolivia, Venezuela, Colombia, Ecuador, Mexico, Argentina, Ethiopia, Armenia and various border zones in highland areas such as the Sino-India border plateau.
