Fashionable Appearance

The streamline handrail of Mitsubishi escalator is elegant and safe. The classic style, gorgeous style (with lighting) and simple style are available for different occasions. With a variety of colors, the handrails can match the cover boards and skirtboards of different textures, to meet the needs of different environments.
The handrail is antibacterial, safe and secure, leading a healthy trend.
It can be mounted on glasses of different colors, and looks elegant.

Optimal Space-Saving Design

The compact design for Mitsubishi escalator significantly reduces the size of the civil engineering, to save space.
a. The minimum span size significantly saves the area of civil engineering.
b. The deep depth of bottom machine room enables a free layout.

Efficient Transmission and Energy Conservation

The high precision and high efficiency helical gear units have a higher efficiency than the conventional worm gear units, fully guaranteeing the efficient use of energy.
For the frequency conversion type Mitsubishi escalator, the passenger flow can be detected in several modes. It stops automatically when there is no passenger, to avoid invalid operation and save electricity.

Safety First Principle of Mitsubishi

Following the consistent tradition of the Shanghai Mitsubishi, the handrail inlet is hidden, greatly reducing the risk of nipping. The long and soft protection cover of handrail inlet adds another protection for passengers.
Stainless steel step with light yellow demarcation on three sides looks nice and reminds passengers to be careful. The black electrophoretic coating makes the steps beautiful and antirust. The safety device even exceeds the national standard. Other functions are also optional, caring for the safety of passengers.
The antibacterial handrail provides safety and eliminates the psychological barrier of passengers.
The disc brake makes the structure more compact and the braking more stable.

Excellent Craftsmanship and Quality

The large-scale special tooling guarantees the accuracy and the quality of escalator.
The drive sprocket directly engages with wear-resistant resin step rollers, to avoid the rigid impact. The engagement is quiet.
Upper and lower reversing mechanism is designed in one piece with the rail to guarantee the seamless transition of curved transmission and reversing, to significantly reduce the horizontal and vertical vibration.
The axis positioning mode improves the engagement accuracy and reduces assembly workload.
The stainless steel landing plate features high intensity, small deformation and h3er wear resistance. It guarantees the quality of the escalator.
The truss is made of steel angles, because it is easy to conduct antirust treatment on steel angles, but difficult on rectangular steel tubes. The rectangular steel tubes are of thin wall, so that the intensity and the rigidity will be largely affected. In terms of same cross section, the truss made of steel angle has a smaller deflection and is difficult to deform.

1. Large assembly tooling
2. Comparison of steel angle and rectangular steel tube
3. Photoelectric sensor of passengers
4. Upper sprockets
5. Disc brake
