Recommended application

The bucket capacity of the HY-610 wheel loader is 0.5m3, and the rated loading weight is 1000kg. The machine adopts four wheel drive and has strong adaptability to working sites, which can be widely used in the construction of highways, mines, brick and tile factories, urban construction, kilns, stone factories, prefabricated cement parts factories and other agricultural engineering as well as medium and small buildings.

According to customers’ requirements, fast connector can be selected for mounting, switching prepositive loader mount attachments, so as to expand the application scope and improve the working efficiency.

  • Fast connector
  • Fast connector
Technical parameters
Rated loading weight 1000kg
Rated bucket capacity 0.5M3
Rated power 25.2,33.7,and 35.7kW
Rated speeds 2200rpm
Bucket width 1550mm
Track base 1200mm
Wheel base 1750mm
Min. swerve diameter 4400mm
Min. ground clearance 240mm
Dump height fully raised 2650mm
Lifting time 4s
Hydraulic cycle time 9s
Max. tilt angle 30°
Max. bucket breakout force, lift cylinder 32KN
Operating weight 2500kg
Dimension(L×W×H) 4530×1500×2500mm
Detailed information
Driving mode Four-wheel drive
Engine model Yanmar4TNV-88- SYY / Yanmar4TNV94L-BVBKC /Perkins404D-22
Engine type In-line arrangement, water cooled, four-stroke diesel Engine
Engine starting mode Electric
Brake mode Four-wheel hydraulic spread-shoed brake
Color According to the requirements of customers
Tyre 12-16.5
Delivery time 25 days after confirm the order
Supply ability 100 units per month
  • Operating lever
  • Steering wheel
  • Adjustable seat

Hongyuan Vehicle has been manufacturing super quality wheel loaders, is offering front end loaders for agricultural and heavy construction industry. By changing the associated implements on the loaders, we can offer a wide range of special purpose loaders, like sugar cane grab loader, log grapple loader, rough terrain forklift truck, snow plow, rock breaker and so on. With rich export experience and quality assurance, we provide custom need farming and construction equipment with competitive prices.
