SL Series Brushless DC Parallel Shaft Gearmotor Manufacturer

SL Series Brushless DC Parallel Shaft Gearmotor

Request a Quote

View All: http://zd-drivers.com/2-2-2-brushless-dc-gear-motor.html

Specifications of Parallel Shaft Gearmotor

Unit: N•m

Output Power	Motor Speed	Gear Ratio
Output Power	Motor Speed	5	7.5	10	15	20	25	30	40	50
100W	80~2000 RPM	1.74	2.61	3.49	5.23	6.97	8.71	10.46	11.62	11.62
	3000 RPM	1.16	1.74	2.32	3.49	4.65	5.81	6.97	9.30	11.62
	4000 RPM	0.87	1.31	1.74	2.61	3.49	4.36	5.23	6.97	8.71

Specifications of Parallel Shaft Gearmotor

Unit: N•m

Output Power	Motor Speed	Gear Ratio
Output Power	Motor Speed	5	7.5	10	15	20	25	30	40	50
200W	80~2000 RPM	3.49	5.23	6.97	10.46	13.94	17.43	20.91	23.24	23.24
	3000 RPM	2.32	3.49	4.65	6.97	9.30	11.62	13.94	18.59	23.24
	4000 RPM	1.74	2.61	3.49	5.23	6.97	8.71	10.46	13.94	17.43

Specifications of Parallel Shaft Gearmotor

Unit: N•m

Output Power	Motor Speed	Gear Ratio
Output Power	Motor Speed	5	7.5	10	15	20	25	30	40	50
400W	80~2000 RPM	6.97	1046	13.94	20.91	27.89	34.86	41.83	46.48	46.48
	3000 RPM	4.65	6.97	9.30	13.94	18.59	23.24	27.89	37.18	46.48
	4000 RPM	3.49	5.23	6.97	10.46	13.94	17.43	20.91	27.89	34.86

Specifications of Parallel Shaft Gearmotor

Unit: N•m

Output Power	Motor Speed	Gear Ratio
Output Power	Motor Speed	5	7.5	10	15	20	25	30	40	50
750W	80~2000 RPM	13.07	19.61	26.14	39.21	52.29	65.36	78.43	87.14	87.14
	3000 RPM	8.71	13.07	17.43	26.14	34.86	43.57	52.29	69.72	87.14
	4000 RPM	6.54	9.80	13.07	19.61	26.14	32.68	39.21	52.29	65.36

Specifications of Parallel Shaft Gearmotor

Unit: N•m

Output Power	Motor Speed	Gear Ratio
Output Power	Motor Speed	5	10	15	20	25	30	40	50	100
1100W	80~2000 RPM	19.17	38.34	57.51	76.69	95.86	115.03	153.37	191.72	191.72
	3000 RPM	12.78	25.56	38.34	51.12	63.91	76.69	102.25	127.81	127.81
	4000 RPM	9.59	19.17	28.76	38.34	47.93	57.51	76.69	95.86	95.86

Established in 1998, Zhongda has grown to become a leading high-tech enterprise in China that combines research, manufacturing, sales, and services in the sector of motor drives, micro motors, precision reducers, and integrated intelligent units. With a registered capital of 104 million Yuan, we have expanded to nine subsidiaries, employing over 1,800 dedicated individuals. In August 2017, we proudly made our mark on the main board of the Shenzhen Stock Exchange under the stock code: 002896.
