Wind Series Fiber Laser Cutting Machine, Wind 3015 / Wind 4020 / Wind 6025/Wind8025
Applicable material:
Carton steel, stainless steel, aluminum alloy, titanium alloy, galvanized sheet, aluminum-zinc coated sheet, brass, red copper and other metal materials
Model | Wind 3015 | Wind 4020 | Wind 6025 | Wind8025 |
Working area | 3000 x 1500 mm | 4000 x 2000 mm | 6000 x 2500 mm | 8000x2500mm |
Output laser power | 3000W/4000W/6000W/8000W/10000W/12000W | |||
Driving system | High-torque servo, both sided driving system | |||
Feeding | Automatic pallet changer | |||
Max. position speed | 200m/min | |||
Acceleration | 2.0 g | |||
Position accuracy | ± 0.05mm (VDI/DGQ 3441) | |||
Reposition accuracy | ± 0.03mm(VDI/DGQ 3441) | |||
Total power | 18-44Kw | |||
Gross weight | 13T | 15.5T | 17.5T | 25.5T |
Overall dimension | 9800x3000x2200 mm | 12000x3500x2200mm | 15500x4200x2200 mm | 19440x4200x2200mm |
Samples:
Features
1. A movable laser head is adopted, which is outfitted with a built-in data base, allowing easy and intelligent operation.
2. Wind series fiber laser cutting machine enjoys a gantry structure and a high-strength frame. It undergoes stress relieving, which allows a high rigidity and small deformation.
3. High-accuracy servo motor and high accuracy driving system are used together in this Wind Series fiber laser cutting machine, allowing a high installation accuracy, large drive torque, small driving tolerance and excellent dynamic characteristics.
4. In strict accordance with the principles of ergonomics, our laser cutting machine is equipped with an intelligent operation terminal, whose operational panel is clearly displayed, allowing an easy operation.
5. Han’s Yueming pioneers the adoption of CCD Hawk-Eye identification technology in China, allowing fast positioning. Besides, second cutting is also available, which helps to achieve a better cutting effect and better scrap cutting.
6. Han’s Yueming developed variable-frequency cutting technology, as well as a punching technology with zoom head. With these technologies, Han’s Yueming is capable to cut plates with different thicknesses and different materials. They also endow our machining higher cutting efficiency and higher cutting effect. Moreover, all the technologies and all the technical parameters involved of the fiber laser cutting machine are digitally controlled, which helps to eliminate manual involvement and allows an easy operation.
7. Wind series fiber laser cutting machine is equipped with an energy-saving device, whose installment adds our fiber laser cutting machine with a hibernation function when the machine has suspend its running for more than 5 min.
8. The fiber laser cutting machine is featured with a patented automatic lifting system, which has an integrated structure and is designed for automatic feeding. Therefore, decreased fault and high stability will be achieved.
9. Servo system of the machine enjoys an automatic controlling towards the pressures released by auxiliary gases, which saves the efforts for manual adjustment and effectively saves the gas’s using in dry running. Thus, a large amount of cost could be saved.
