LE2914 Single Face LED Emergency Exit Box with Metal Housing
Request a Quote
Exit Lights
- Single-face LED emergency exit box with a modern enclosure design
- Constructed with a steel housing and acrylic panel for enhanced durability
- Provides up to 3 hours of continuous emergency illumination
- Designed for wall-mounted indoor applications
- Ingress protection rating: IP20
Specifications
| Model | LE2914 | ||
| Mode of Operation | Maintained | ||
| Product Material | Steel housing, PMMA exit sign panel | ||
| Voltage | 220-240V /50-60Hz | ||
| Power Consumption | 4.5W | ||
| Output Voltage | 3.6V | ||
| Output Power | 2.5W | ||
| Lumen Output | 126lm | ||
| Battery | 3.6V 1.8Ah Ni-Cad | ||
| Max. Change Current | 70mA | ||
| Max. Discharge Current | 700mA | ||
| Charging Time | 24H | ||
| Discharging Time | 3H | ||
| Lamp | SMD 5050LED 12pcs | ||
| Certifications | CE, ROHS, IEC, BS, GS | ||
| Product Size | 390×62×190mm | ||
| Remarks | 1 type of sign panel artwork included, single face | ||
| Ordering and Packing Information | |||
| MOQ | 1000pcs | ||
| Lead Time | 35 days | ||
| Sample Delivery Time | 3~10 days | ||
| Packing | White box | ||
| Carton Size (L×W×H) | 44.5×41×21.8cm | ||
| Carton CBM | 0.04m³ | ||
| Quantity per Carton | 6pcs | ||
| Gross Weight | 6.5kgs/ctn | ||
| Net Weight | 5.5kgs/ctn | ||
| Container Loading Quantity | 1×20' | 1×40' | 1×40' HQ |
| 4125pcs | 8625pcs | 10050pcs | |
