High Pressure Fixed Displacement Vane Pump
Request a Quote
Features
- This pump features a low-noise, high-volumetric efficiency design.
- It offers smooth operation, high stability, and a long lifespan.
- The suction port is specially designed to optimize its suction resistance.
- It supports a maximum pressure of 21MPa.
Technical Specifications
| Model | Delivery capacity (cc/rev) | Max. pressure (kgf/cm²) | Speed (rpm) | ||||
| Max. | Min. | ||||||
| at 1000rpm | at 1200rpm | at 1500rpm | at 1800rpm | ||||
| | 6.2 | 7.4 | 9.3 | 11.2 | 210 | 1800 | 1200 |
| | 8.1 | 9.4 | 12.1 | 14.6 | 210 | 1800 | 950 |
| | 10.1 | 12.1 | 15.1 | 18.9 | 245 | 1800 | 950 |
| | 12.2 | 14.6 | 18.3 | 21.9 | 245 | 1800 | 950 |
| | 13.6 | 17.1 | 21.5 | 25.7 | 245 | 1800 | 950 |
| | 16.6 | 20.5 | 25.6 | 0.7 | 245 | 1800 | 950 |
| | 18.6 | 23 | 28.8 | 34.5 | 245 | 1800 | 950 |
| | 22.7 | 27.9 | 34.9 | 41.9 | 245 | 1800 | 950 |
| | 25.3 | 31.3 | 39.1 | 46.9 | 245 | 1800 | 950 |
| | 31 | 37.3 | 46.6 | — | 245 | 1500 | 950 |
| | 26.2 | 31.4 | 39.3 | 47.1 | 245 | 1800 | 950 |
| | 33 | 38.5 | 48.1 | 57.7 | 245 | 1800 | 950 |
| | 38.2 | 45.8 | 57.3 | 68.7 | 245 | 1800 | 950 |
| | 41.3 | 49.2 | 61.5 | 73.8 | 210 | 1800 | 950 |
| | 47.2 | 57.8 | 71.4 | 86.7 | 245 | 1800 | 950 |
| | 53.1 | 63.7 | 79.6 | 95.5 | 245 | 1800 | 950 |
| | 60.2 | 72.7 | 90.3 | 108.3 | 210 | 1800 | 950 |
| | 65.3 | 78.3 | 97.9 | 117.5 | 210 | 1800 | 950 |
| | 60.3 | 72.3 | 90.4 | 108.5 | 210 | 1800 | 900 |
| | 66.4 | 79.6 | 99.6 | 119.5 | 210 | 1800 | 900 |
| | 76.3 | 91.5 | 114.4 | 137.3 | 210 | 1800 | 900 |
| | 84.5 | 101.4 | 126.7 | 152.1 | 210 | 1800 | 900 |
| | 88.3 | 105.9 | 132.4 | 158.9 | 210 | 1800 | 900 |
| | 93.6 | 113.4 | 141.7 | 170.1 | 210 | 1800 | 900 |
| | 108.2 | 129.8 | 162.3 | 194.4 | 210 | 1800 | 900 |
| | 115.6 | 139.3 | 174.1 | 208.9 | 175 | 1800 | 900 |
| | 125.6 | 149.5 | 186.9 | 226 | 175 | 1500 | 900 |
