Commercial Electric 3 Wheeler Manufacturer

Commercial Electric 3 Wheeler

Request a Quote

View All: http://rapelectricvehicle.com/2019/2-2-commercial-electric-3-wheeler.html

This product has been discontinued and removed from our shelves.

The container on this commercial electric 3 wheeler is divided into two layers: one for cooling goods, and the other is a heat trap box with a temperature range of -2℃ to 65℃, ensuring food remains at the optimal temperature until deliver.

Commercial electric 3 wheeler equipped with hot and cold mode container could bring great convenience to the delivery man when delivering food, and could ensure the best eating condition of the food.

Parameter

Performance

Battery

Electric machinery

Container

Safety

Materials of Commercial Electric 3 Wheeler

Main material for portable cargo compartment：EPP
Hinge: 304 stainless steel
Bolt: 304 stainless steel
Partition: Celuka PVC foam board
Shield for cargo compartment: oxford cloth/Aluminum based coating
Ice pack: HDPE housing ice gel

Fast charging

Shared charging station
Home Charger

	Fast charging	Slow charging
Max. input current	≤16A	≤7.5A
Rated power	2000W	1000W
Output current	40A	15A
Conversion efficiency at maximum power output	≥90%	≥90%
Working temperature (℃)	-25~55	-25~55
SOC0-SOC100% charging time (h)	3	6.5
SOC20%-SOC90% charging time (h)	2	5

Gallery

Right handlebar
Left handlebar
Rock and parking brake handle
Hub motor
Driver seat
Chinese Calligraphy Safe Journey
Display screen –reversing camera display
Front wheel disc brake
Storage box
Hourglass headlights
Dashboard storage box
Glove compartment
Charge port
USB port
Power port
Tools

Features of commercial electric 3 wheeler

The electric cargo scooter comes with a cargo compartment mainly made using EPP. With thermal conductivity ≤0.033, good heat preservation is ensured during food storage.
The EPP foam features high impact resistance and good rebound resilience, prolonging cargo compartment’s lifetime.
The EPP foam has very good resistance to oil, water and chemical, and complies with food grade standards, making the cargo compartment suitable for safely storing and transporting all types of food.
The EPP box has hot and cold layers with customized temperature from -2 ℃ to 65 ℃.
With a capacity of 200L, the cargo compartment features a 2-layer structure:
Insulation layer on the top: with heating device inside, the temperature increase can achieve up to 20℃ within 15 minutes.
Refrigeration layer on the bottom: due to the ice pack inside, the temperature of cold beverages can be maintained as low as -10℃ for more than 5 hours. In addition, the cargo compartment is designed with cup holders and temperature display for monitoring cargo temperature anytime.
The cargo compartment is shielded with oxford fabric. This delays its aging process. In addition, various printings can be made on the fabric for better visual effect.

Custom Commercial Electric 3 Wheeler
