Duplex Slitter Rewinder for Nonwoven Fabric
Request a Quote
Model: PPD-NW1300
Max. web width: 1300mm
Max. rewind diameter: 600mm
Max. unwind diameter: 1200mm
Slitting width: 25-1300mm
Slitting accuracy: ±0.2mm
Slitting speed: 200m/min
Cutting method: circular knife Voltage: 380V
Applications
This duplex slitter rewinder is designed for converting larger diameter rolls of spunlace nonwoven, needle-punched nonwoven, PP-spunbond nonwoven and other nonwoven fabrics to narrower rolls. Dual station for simultaneous rewinding with variable frequency speed control provides high efficiency and simple operation.
- Integrating functions of slitting, rewinding and waste trim removal, with smooth cut-edge;
- High precision length measurement, automatic shutdown of the machine;
- Magnetic powder brake for web tension control;
- 3" air shaft chain-driven rewinding, higher stability;
