Tilt Back Tire Changer

Tilt Back Tire Changer
Request a Quote

Nearly 2 decades of experience in manufacturing custom vehicle maintenance equipment, our products have been exported to more than 60 countries

Tilt back tire changers are without a doubt the ideal choice for most tire plants. The tilt-back design offers operators more space and leverage, which can reduce the likelihood of wheels becoming damaged. Therefore, they are suitable for servicing high-end wheels.

The design of the foot-pedal control simplifies the job. The operator just needs to depress the foot pedals, the tilt-back tower will move to the suitable position. This method for demounting the tire can reduce fatigue and improve efficiency. Most plants with large tire handling capacity use tilt back tire changers.

Although the price of tilt back tire changer is higher than swim arm tire changers, it has the advantage of easy operation and high efficiency. Besides that, tilt back tire changers will not damage the tire even when operated by unskilled operators.

Parameter
Type WM-TC004
Power 1.1kw/0.75kw
Voltage 220v/380v
Operating air-pressure 0.7-0.8MPa
Max Tire Diameter 800mm
Outside clamping range 10-22''
Inside clamping range 12-24''
Bead breaker shovel force 2500kg
Shipping Dimensions 1220*900*400mm
Net Weight 276kg
Overall Weight 336kg
Feature

1. Pneumatic control valves are made of die cast aluminum, which increase the lifespan of your tire changer.

2. Four clamping jaws are controlled by dual pneumatic clamping cylinders, which prevents damage of tires resulting from slipping.

3. Clamping jaws are made of precision cast steel, sturdy and durable.

4. Control the rotating speed of the turntable to minimize tire damage and reduce mounting and demounting time.

5. Plastic components are equipped to avoid damaging tires.

6. Special clamping tools and bead breaker lever for motorcycles.
