Semi-automatic Tire Changer
Request a Quote
Nearly 2 decades of experience in manufacturing custom vehicle maintenance equipment, our products have been exported to more than 60 countries
When using a semi-automatic tire changer, the lever needs to be put on the groove in the hub manually. However, the advantages of small installation space and low price let semi-automatic tire changer be widely applied to small vehicles repair shops.
Parameter
Type | WM-TC002A | WM-TC002B | WM-TC003C | WM-TC003D |
Power | 1.1kw/0.75kw | 1.1kw/0.75kw | 1.1kw/0.75kw | 1.1kw/0.75kw |
Voltage | 220v/380v | 110v/220v-1ph 220v/380v-3ph 50/60hz | 220v/380v | 220v/380v |
Operating air-pressure | 0.7-0.8MPa | 0.7-0.8MPa | 0.7-0.8MPa | 0.7-0.8MPa |
Max Tire Diameter | 650mm | 750mm | 650mm | 800mm |
Outside clamping range | 10-17'' | 13-24'' | 10-17'' | 10-22'' |
Inside clamping range | 12-20'' | 12-20'' | 12-24'' | |
Bead breaker shovel force | 2500kg | 2500kg | 2500kg | 2500kg |
Shipping Dimensions | 1050*850*950mm | 1130*950*930mm | 1050*850*950mm | 1220*900*400mm |
Net Weight | 170kg | 192kg | 170kg | 276kg |
Overall Weight | 215kg | 242kg | 215kg | 336kg |
Feature
1. This semi-automatic tire changer can mount and dismount tire with a diameter of 31 inches.
2. The foot pedals are made of high-strength aluminum alloy.
3. Four clamping jaws are controlled by dual pneumatic clamping cylinders, which prevents damage to tires resulting from slipping.
4. Four-jaw clamping chuck is equipped with changeable plastic accessories to protect tires.
5. The capacity of the bead breaker shovel can reach 2500kg, it can easily loosen any tire.
