Automatic Tire Changer

Automatic Tire Changer
Request a Quote

Nearly 2 decades of experience in manufacturing custom vehicle maintenance equipment, our products have been exported to more than 60 countries

In the process of using an automatic tire changer, the machine will put the lever on the groove of the hub automatically. Because of that, the workload of operators is reduced. The semi-automatic tire changer is widely applied to vehicles repair plants where the automation degree and labor costs are both high.

Parameter
Type WM-TC001B WM-TC001C WM-TC001D
Power 1.1kw/0.75kw 1.1kw/0.75kw 1.1kw/0.75kw
Voltage 220v/380v 220v/380v 220v/380v
Operating air-pressure 0.7-0.8MPa 0.7-0.8MPa 0.7-0.8MPa
Max Tire Diameter 960mm 960mm 1040mm
Outside clamping range 10-22'' 10-22'' 12-24''
Inside clamping range 13-24'' 13-28'' 12-24''
Bead breaker shovel force 2500kg 2500kg 2500kg
Shipping Dimensions 1220*900*400mm 1220*900*400mm 1050*850*950mm
Net Weight 292kg 292kg 170kg
Overall Weight 367kg 367kg 215kg
Feature

1. This semi-automatic tire changer can mount and dismount tire with diameter of 40 inches.

2. The foot pedals is made of high-strength aluminum alloy, lightweight and durable.

3. Four clamping jaws are controlled by dual pneumatic clamping cylinders, which avoids damage of tires resulting from slipping.

4. Four-jaw clamping chuck is equipped with changeable plastic accessories to protect tires.

5. The capacity of bead breaker shovel can reach 2500kg, it can easily loosen any tire.
