Tabletop Tablet Counter

Request a Quote

View All: http://upg-printpacking.com/2-6-2-tabletop-tablet-counter.html

LQ-YL

Counting system for filling bottles with tablets, capsules, and soft gels

Designed to enhance the process of filling bottles with tablets, capsules, and soft gels, the tabletop tablet counter is a compact and efficient solution that fits seamlessly into any pharmaceutical, healthcare, or laboratory setting. This counter is known for its precision and ease of use, making it an ideal choice for operations looking to enhance productivity without the complexity.

With its robust stainless steel construction and a host of intuitive features, this machine ensures accurate counting and packaging of various medicinal pellets, combining durability with high operational standards.

Specifications

Model	LQ-YL-2A	LQ-YL-2	LQ-YL-4
Capacity	500-1500pcs/min	1000-1800pcs/min	2000-3500pcs/min
Overall Dimensions (L×W ×H)	427mm×327mm×525mm	760mm×660mm×700mm	920mm×750mm×810mm
Voltage	110-220V, 50Hz-60Hz, 1Ph	110-220V, 50Hz-60Hz, 1Ph	110-220V, 50Hz-60Hz, 1Ph
Net Weight	35kg	50kg	85kg

Features

The counting range for tablets, capsules, or soft gels can be set anywhere from 0 to 9999, allowing for flexible and precise control over the number of units in each bottle.
The entire body of the tablet counter is made from stainless steel, which meets GMP specifications. This ensures operations remain clean and free from contamination, maintaining a hygienic environment
This tablet counting machine is user-friendly, requiring no specialized training. Operators can efficiently run it after a brief orientation, simplifying the packaging process
Equipped with a precision counting feature and a photoelectric sensor, the counter reliably ensures accurate counts every time. This boosts the reliability of your packaging process and helps avoid errors.
The rotary counting design facilitates a fast and fluid operation. The counting speed can be adjusted seamlessly according to the bottle’s feed rate, making the tablet counting machine adaptable to different operational speeds.
The vibration frequency in the particle hopper is fully adjustable, allowing you to tailor the feeding mechanism to the specific needs of the tablets, capsules, or soft gels. This ensures consistent and uninterrupted feeding.
For the LQ-YL-2 model, the process starts with one bottle and automatically counts the next once the current one is filled. This setup makes it easy for operators to manage bottles one at a time.
For the LQ-YL-4 model, it handles two bottles at a start and moves to the next pair once the first is done. This approach doubles the efficiency, making it perfect for higher-volume operations.
