LQ-ZP

Multi-station tablet compression machine for mass production of tablets

The rotary tablet press is a multi-station tablet compression machine, engineered for high-volume production of tablets. This continuous automatic press is especially well-suited for the pharmaceutical industry but is also extensively used in chemical, food, electronic, plastic, and metallurgical sectors. Designed with a focus on efficiency and compliance, the rotary label prince integrates advanced features for operation stability and guaranteed product quality.

Specifications

Model	LQ-ZP11D	LQ-ZP15D	LQ-ZP17D	LQ-ZP19D	LQ-ZP21D
Quantity of Die	11	15	17	19	21
Max. Working Pressure	100KN	80KN	60KN	60KN	60KN
Max. Tablet Diameter	40mm	25mm	20mm	15mm	12mm
Max. Tablet Thickness	28mm	15mm	15mm	15mm	15mm
Max. Filling Depth	10mm	6mm	6mm	6mm	6mm
Rotation Speed	20rpm	30rpm	30rpm	30rpm	30rpm
Max. Capacity	13200pcs/h	27000pcs/h	30600pcs/h	34200pcs/h	37800pcs/h
Power	3kW	3kW	3kW	3kW	3kW
Voltage	380V, 50Hz, 3Ph	380V, 50Hz, 3Ph	380V, 50Hz, 3Ph	380V, 50Hz, 3Ph	380V, 50Hz, 3Ph
Overall Dimensions (L×W×H)	890×620×1500mm	890×620×1500mm	890×620×1500mm	890×620×1500mm	890×620×1500mm
Weight	1000kg	1000kg	1000kg	1000kg	1000kg

Features

The tablet press exterior is completely enclosed and constructed from stainless steel, fulfilling GMP standards and ensuring durability and ease of cleaning.
Equipped with clear windows that allow operators to monitor the pressing process. These windows can also be opened to facilitate easy access for cleaning and maintenance.
Capable of exerting high pressure, this machine can handle the production of large-sized tablets as well as small batches of various shapes, including round, irregular, and annular tablets.
All controls and devices are conveniently located on one side of the tablet press, enhancing operational ease. It includes an overload protection unit to safeguard the punches and machinery from damage during overload conditions.
Features an oil-immersed lubrication system within a fully-enclosed worm gear drive, which not only extends the service life of the components but also prevents cross-contamination.
