Single Punch Tablet Press

Single Punch Tablet Press
Single Punch Tablet Press
Request a Quote
LQ-TDP

Single station tableting machine for compressing pharmaceutical powders and granules into tablets

  • The single punch tablet press is a compact, single-station tableting machine designed specifically for the compression of pharmaceutical powders and granules into tablets. Ideal for laboratory trials and small-batch production, this machine can mold various granular raw materials into round tablets, as well as other shapes like sugar pieces, calcium tablets, and tablets of abnormal shapes. Its desktop design makes it highly suitable for settings where space is at a premium and where flexibility in production is required.

    Specifications
    Model LQ-TDP-0 LQ-TDP-1 LQ-TDP-2 LQ-TDP-3 LQ-TDP-4 LQ-TDP-5 LQ-TDP-6
    Max. Pressure 10 KN 15 KN 20 KN 30 KN 40 KN 50 KN 60 KN
    Max. Tablet Diameter 10mm 12mm 13mm 14mm 15mm 22mm 25mm
    Max. Tablet Thickness 6mm 6mm 6mm 6mm 6mm 7mm 7.5mm
    Max. Filling Depth 12mm 12mm 12mm 12mm 12mm 15mm 15mm
    Capacity 6000 pcs/h 6000 pcs/h 6000 pcs/h 6000 pcs/h 6000 pcs/h 3600 pcs/h 3600 pcs/h
    Voltage 220V / 50Hz / 1Ph 220V / 50Hz / 1Ph 220V / 50Hz / 1Ph 220V / 50Hz / 1Ph 220V / 50Hz / 1Ph 220V / 50Hz / 1Ph 220V / 50Hz / 1Ph
    Power 0.37W 0.37W 0.37W 0.55W 0.55W 0.75W 1.1W
    Overall Dimensions (L×W×H) 530×340×570mm 530×340×570mm 530×360×570mm 680×440×740mm 680×450×740mm 600×500×700mm 650×500×700mm
    Weight 35kg 60kg 75kg 80kg 95kg 150kg 165kg
    Applications

    This machine is particularly useful in pharmaceutical research and development labs where new formulations are tested. It is also perfect for small-scale production facilities that require the ability to quickly switch between different types of tablets or experimental batches. The simplicity of the design allows for ease of use in educational settings, where students can learn about the tablet manufacturing process hands-on.

    Features
    • Built to meet Good Manufacturing Practices standards, ensuring that it meets the stringent requirements of the pharmaceutical industry
    • Offers high-quality tablet pressing capabilities at a low cost, providing great value for small labs and production facilities
    • Designed with simplicity in mind, it features parts that are easy to remove for quick and straightforward maintenance. This reduces downtime and ensures continuous operation
    • Allows for adjustments in both the filling depth of the material and the thickness of the tablet, providing flexibility to accommodate various product specifications
