Commercial / Residential Evaporative Cooler Manufacturer

Commercial / Residential Evaporative Cooler

Request a Quote

View All: http://evaporation-cooler.com/2-commercial-residential-evaporative-cooler.html

KEYE has over a decade of experience in manufacturing industrial air coolers where environmental conditions are more complex, this means we are capable enough of manufacturing high performance and high durability commercial & residential evaporative coolers.

Our commercial and residential evaporative coolers are suitable for both outdoor and indoor applications, such as conference rooms, houses, hotels, private clubs, beauty salons, gyms, waiting rooms, restaurants and other working or living spaces.

Motor: insulation class B, protection class IP54, high-temperature and high-humidity resistance, high cooling efficiency, low noise level and stable motor startup;
Fan blade: high quality plastic die-cast blades, designed in accordance with fluid dynamics and aerodynamics, providing streamlined blade curve, less sound level and large volumes of air;
Evaporative media: the cooling pads are specially crafted paper in a honeycomb structure, the cross-fluted design promotes the capability of absorbing and retaining water to achieve better cooling efficiency, while preventing mildew forming on the media and providing longer service life;

Cooling area

Residential Evaporative Cooler, Mobile Swamp Cooler, 350m³/h

Model: GC-30Y

Max. air flow: 350m³/h
Fan type: cross flow fan
Voltage/Frequency: 220V/50Hz
Power: 48W
Operating current: 0.21A
Water tank capacity: 8.5L
Overall size: 280×263×728mm
Air outlet size: 167×377mm
Noise: ≤53dB
Net weight: 6.5kg
Cooling area: 10-20m²
Fan speed: 3
Full electronic control
Swivel casters

Residential Evaporative Cooler, Mobile Swamp Cooler, 3500m³/h

Model: ZC-35Y

Max. air flow: 3500m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.12kW
Operating current: 0.55A
Water tank capacity: 25L
Overall size: 495×350×890mm
Air outlet size: 380×438mm
Noise: ≤61dB
Net weight: 20kg
Cooling area: 10-30m²
Fan speed: 3
Multifunctional touch panel control
Swivel casters

Residential Evaporative Cooler, Portable Evaporative Cooler, 3500m³/h

Model: ZC-36Y

Max. air flow: 3500m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.12kW
Operating current: 0.55A
Water tank capacity: 28L
Overall size: 495×350×1042mm
Air outlet size: 380×438mm
Noise: ≤61dB
Net weight: 23kg
Cooling area: 10-30m²
Fan speed: 3
Multifunctional touch panel control

Residential Evaporative Cooler, Portable Swamp Cooler, 4800m³/h

Model: ZC-40Y

Max. air flow: 4800m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.23kW
Operating current: 1.0A
Water tank capacity: 45L
Overall size: 620×500×1080mm
Air outlet size: 494×560mm
Noise: ≤62dB
Net weight: 26kg
Cooling area: 20-40m²
Fan speed: 3
Digital touch panel control

Residential Evaporative Cooler, Mobile Swamp Cooler, 4800m³/h

Model: ZC-40Y1

Max. air flow: 4800m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.23kW
Operating current: 1.0A
Water tank capacity: 45L
Overall size: 620×500×1080mm
Air outlet size: 494×560mm
Noise: ≤62dB
Net weight: 26kg
Cooling area: 20-40m²
Fan speed: 3
Multifunctional touch panel control

Residential Evaporative Cooler, Mobile Swamp Cooler, 5000m³/h

Model: ZC-62Y

Max. air flow: 5000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.23kW
Operating current: 1.0A
Water tank capacity: 75L
Overall size: 560×410×1660mm
Air outlet size: 500×500mm
Noise: ≤62dB
Net weight: 31kg
Cooling area: 20-40m²
Fan speed: 3
Digital touch panel control

Residential Evaporative Cooler, Mobile Swamp Cooler, 6800m³/h

Model: ZC-76Y

Max. air flow: 6800m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.3kW
Operating current: 1.3A
Water tank capacity: 38L
Overall size: 860×500×1080mm
Air outlet size: 605×635mm
Noise: ≤64dB
Net weight: 33kg
Cooling area: 30-60m²
Fan speed: 3

VIDEO

Residential Evaporative Cooler, Mobile Evaporative Cooler, 6800m³/h

Model: ZC-76Y3

Max. air flow: 6800m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.3kW
Operating current: 1.3A
Water tank capacity: 120L
Overall size: 860×500×1380mm
Air outlet size: 605×635mm
Noise: ≤64dB
Net weight: 37kg
Cooling area: 30-60m²
Fan speed: 3

Residential Evaporative Cooler, Mobile Evaporative Cooler, 8000m³/h

Model: LC-80Y

Max. air flow: 8000m³/h
Fan type: centrifugal
Voltage/Frequency: 220V/50Hz
Power: 0.45kW
Operating current: 2.0A
Water tank capacity: 38L
Overall size: 840×490×1080mm
Air outlet size: 720×220mm
Noise: ≤64dB
Net weight: 36kg
Cooling area: 30-60m²
Fan speed: 3
Plastic impeller: multi-vane centrifugal impeller (squirrel cage impeller), high speed, lightweight and low noise level;

Residential Evaporative Cooler, Portable Evaporative Cooler, 8000m³/h

Model: LC-80Y3

Max. air flow: 8000m³/h
Fan type: centrifugal
Voltage/Frequency: 220V/50Hz
Power: 0.45kW
Operating current: 2.0A
Water tank capacity: 120L
Overall size: 840×490×1380mm
Air outlet size: 720×220mm
Noise: ≤64dB
Net weight: 39.5kg
Cooling area: 30-60m²
Fan speed: 3
