Mobile Evaporative Air Cooler (Large-scale) Manufacturer

Mobile Evaporative Air Cooler (Large-scale)

Request a Quote

View All: http://asphaltmixsolution.com/7-1-large-scale-bitumen-storage-silo.html

Unlike residential desktop evaporative coolers, these industrial mobile evaporative coolers feature higher volume, weight and power, and can deliver larger air flow. The design of casters allow for easy mobility from one space to another.

Product volume: 0.760m³-2.347m³

Weight: 50kg-114kg

Air flow: 13000m³/h-18000m³/h

Power: 550W-1100W

Cooling area

Applications

Our industrial mobile evaporative coolers are typically suitable for injection molding plants, rubber factories, leather factories, metal stamping workshops, tooling & mold fabrication companies, glass factories, electronics workshops, garment & footwear factories, packaging & printing companies, food processing plants, and more factories and workshops where cooling is required.

Portable Evaporative Cooler, Industrial Air Cooler, 50-80m²

Model: ZC-13Y

Max. air flow: 13000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.6kW
Operating current: 2.8A
Water tank capacity: 145L (can be used for 6-12 hours)
Overall size: 915×545×1525mm
Air outlet size: 650×650mm
Noise: ≤72dB
Net weight: 50kg
Cooling area: 50-80m²
Fan speed: 3
Oscillating louvers can be kept closed when not in use, preventing dust particles and insects from entering the cooler;

Mobile Evaporative Cooler, Industrial Evaporative Cooler, 60-100m²

Model: ZC-76Y3-2

Max. air flow: 13600m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 0.55kW
Operating current: 2.5A
Water tank capacity: 120L (can be used for 3-6 hours)
Overall size: 860×720×2190mm
Air outlet size: 605×635mm
Noise: ≤69dB
Net weight: 71kg
Cooling area: 60-100m²
Fan speed: 3
Horizontal oscillating louvers are electrically driven to move air from side to side, and vertical air flow can be changed by manually adjusting the louvers;

VIDEO

Evaporative Air Cooler, Mobile Evaporative Cooler, 80-100m²

Model: ZC/BP-18Y6

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 1.1kW
Operating current: 7.5A
Water tank capacity: 240L
Overall size: 1220×1100×1250mm
Air outlet size: 640×640mm
Noise: ≤71dB
Net weight: 102kg
Cooling area: 80-100m²
Fan speed: 12
Oscillating louvers can be kept closed when not in use, preventing dust particles and insects from entering the cooler;

Mobile Evaporative Cooler, Industrial Evaporative Cooler, 80-100m²

Model: ZC-18Y6

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 380V/50Hz
Power: 1.1kW
Operating current: 2.8A
Water tank capacity: 240L
Overall size: 1220×1100×1250mm
Air outlet size: 640×640mm
Noise: ≤71dB
Net weight: 102kg
Cooling area: 80-100m²
Fan speed: 1
Oscillating louvers can be kept closed when not in use, preventing dust particles and insects from entering the cooler;

Mobile Evaporative Cooler, Industrial Evaporative Cooler, 80-100m²

Model: ZC-18Y6-H

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 380V/50Hz
Power: 1.1kW
Operating current: 2.8A
Water tank capacity: 240L
Overall size: 1220×1100×1650mm
Air outlet size: 640×640mm
Noise: ≤71dB
Net weight: 116kg
Cooling area: 80-100m²
Fan speed: 1
Oscillating louvers can be kept closed when not in use, preventing dust particles and insects from entering the cooler;
Air cooler stand with wheels, easy to carry and move;

Mobile Evaporative Cooler, Industrial Swamp Cooler, 80-100m²

Model: ZC/BP-18Y6-H

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 1.1kW
Operating current: 7.5A
Water tank capacity: 240L
Overall size: 1220×1100×1650mm
Air outlet size: 640×640mm
Noise: ≤71dB
Net weight: 116kg
Cooling area: 80-100m²
Fan speed: 12
Oscillating louvers can be kept closed when not in use, preventing dust particles and insects from entering the cooler;
Air cooler stand with wheels, easy to carry and move;

Mobile Evaporative Cooler, Industrial Swamp Cooler, 100-150m²

Model: ZS/BP-18Y1

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 1.1kW
Operating current: 7.5A
Water supply: connecting to garden hose
Overall size: 1100×1100×1800mm
Air outlet size: 590×428mm
Noise: ≤71dB
Net weight: 92kg
Cooling area: 100-150m²
Fan speed: 12
Electrically driven oscillating louvers, adopting louver motor with low noise level;
High strength plastic housing, efficiently blowing cooled air;
Welded air cooler stand, high load-bearing capacity;

VIDEO

Mobile Evaporative Cooler, Industrial Swamp Cooler, 100-150m²

Model: ZS/BP-18Y6

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 1.1kW
Operating current: 7.5A
Water tank capacity: 240L
Overall size: 1100×1100×1940mm
Air outlet size: 590×428mm
Noise: ≤71dB
Net weight: 105kg
Cooling area: 100-150m²
Fan speed: 12
Electrically driven oscillating louvers, adopting louver motor with low noise level;
High strength plastic housing, efficiently blowing cooled air;

Mobile Evaporative Cooler, Industrial Evaporative Cooler, 100-150m²

Model: ZS/BP-18Y2

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 1.1kW
Operating current: 7.5A
Water supply: connecting to garden hose
Overall size: 1100×1100×1400mm
Air outlet size: 565×240mm
Noise: ≤71dB
Net weight: 93kg
Cooling area: 100-150m²
Fan speed: 12
The unique design of air outlet increases airflow rate and ensures the balance of air intake and air delivery, while lowering noise level and improving cooler effectiveness;
Welded air cooler stand, high load-bearing capacity;

Mobile Evaporative Cooler, Industrial Evaporative Cooler, 100-150m²

Model: ZS/BP-18Y6-4

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 220V/50Hz
Power: 1.1kW
Operating current: 7.5A
Water tank capacity: 240L
Overall size: 1100×1100×1600mm
Air outlet size: 565×240mm
Noise: ≤71dB
Net weight: 114kg
Cooling area: 100-150m²
Fan speed: 12
The unique design of air outlet increases airflow rate and ensures the balance of air intake and air delivery, while lowering noise level and improving cooler effectiveness;

Mobile Evaporative Cooler, Industrial Swamp Cooler, 100-150m²

Model: ZS-18Y1

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 380V/50Hz
Power: 1.1kW
Operating current: 2.8A
Water supply: connecting to garden hose
Overall size: 1100×1100×1800mm
Air outlet size: 590×428mm
Noise: ≤71dB
Net weight: 92kg
Cooling area: 100-150m²
Fan speed: 1
Welded air cooler stand, high load-bearing capacity;
Electrically driven oscillating louvers, adopting louver motor with low noise level;

Mobile Evaporative Cooler, Industrial Swamp Cooler, 100-150m²

Model: ZS-18Y6

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 380V/50Hz
Power: 1.1kW
Operating current: 2.8A
Water tank capacity: 240L
Overall size: 1100×1100×1940mm
Air outlet size: 590×428mm
Noise: ≤71dB
Net weight: 105kg
Cooling area: 100-150m²
Fan speed: 1
Electrically driven oscillating louvers, adopting louver motor with low noise level;
High strength plastic housing, efficiently blowing cooled air;

Mobile Evaporative Cooler, Industrial Evaporative Cooler, 100-150m²

Model: ZS-18Y2

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 380V/50Hz
Power: 1.1kW
Operating current: 2.8A
Water supply: connecting to garden hose
Overall size: 1100×1100×1400mm
Air outlet size: 565×240mm
Noise: ≤71dB
Net weight: 93kg
Cooling area: 100-150m²
Fan speed: 1
The unique design of air outlet increases airflow rate and ensures the balance of air intake and air delivery, while lowering noise level and improving cooler effectiveness;
Welded air cooler stand, high load-bearing capacity;

Mobile Evaporative Cooler, Industrial Swamp Cooler, 100-150m²

Model: ZS-18Y6-4

Max. air flow: 18000m³/h
Fan type: axial flow
Voltage/Frequency: 380V/50Hz
Power: 1.1kW
Operating current: 2.8A
Water tank capacity: 240L
Overall size: 1100×1100×1600mm
Air outlet size: 565×240mm
Noise: ≤71dB
Net weight: 114kg
Cooling area: 100-150m²
Fan speed: 1
The unique design of air outlet increases airflow rate and ensures the balance of air intake and air delivery, while lowering noise level and improving cooler effectiveness;
