YHS Double Acting Hydraulic Actuator Manufacturer

YHS Double Acting Hydraulic Actuator

Request a Quote

View All: http://ship-machinery.com/3-1-1-double-acting-hydraulic-actuator.html

Parameters

1. Max. working pressure: 11Mpa
2. Rotating angle: 90°±5°
3. Viscosity of hydraulic oil: 22~46cSt/40℃
4. Ambient temperature: -20℃~ +80℃
5. Flange: ISO5211
6. Output signal: Open/close or 4~20mA
7. Protection grade of signal box: IP65/IP68 ExiaⅡ CT4
8. Torque data

Model	YHS32	YHS40	YHS50	YHS63	YHS80	YHS100	YHS125
Torque/N·m	146	275	646	1318	2813	5652	9520

Features

The YHS hydraulic actuator is driven by hydraulic power transmission system. Its performance is stable, low consumption and low noise, making it ideal for use in pinion and rack transmission systems.
YHS hydraulic actuators use a modular and integrated design, with the functions customized to specific needs.
The main body of the YHS hydraulic actuator is designed with a sectional structure, and seals for the oil tank can be directly changed, making maintenance easy.
The square leverage on the top of the YHS hydraulic actuator is optimized in order to be completely independent of the hydraulic system.

Options

Manual worm gear: The YHS hydraulic actuator can be operated manually during power failure periods.
Special modular valve block: The YHS hydraulic actuator is equipped with a special modular valve block, which can conduct emergency operation.
Special connection mode: Special connection modes are useful for easy connection to the micropower unit.
