YHD Single Acting Hydraulic Actuator

YHD Single Acting Hydraulic Actuator
Request a Quote
Parameters

1. Max. working pressure: 11MPa
2. Rotating angle: 90°±5°
3. Viscosity of hydraulic oil: 22~46cSt/40℃
4. Ambient temperature: -20~80℃
5. Flange dimension: ISO5211
6. Output signal: Open/close or 4~20mA
7. Protection grade of signal box: IP65/IP68 ExiaⅡ CT4
8. Torque data

Model YHD40 YHD50 YHD63 YHD80
Torque/N·m 146 275 646 1318
Features
  • The YHD single acting hydraulic actuator is driven using a hydraulic power transmission system that features a compact structure, steady performance, low energy consumption and low noise levels.
  • The YHD hydraulic actuator uses butterfly springs, which produce a larger driving force when closing in order to reduce the valve closing time.
  • An adjusting screw is added to the spring end of the YHD hydraulic actuator in order to adjust the open valve position.
  • The YHD hydraulic actuator can be submerged for installation, making operation convenient.
  • An emergency valve block can be coordinated with the emergency hand pump to conduct emergency operations on valves when the system fails.
  • YHD hydraulic actuator uses a modular and integrated design, with functions customizable to customer needs.
  • The main body of the YHD hydraulic actuator is designed with sectional structure, and the oil tank seals can be directly changed, making maintenance easy.
Options
  • Manual worm gear: The YHD hydraulic actuator can be operated manually during power failures.
  • Special modular valve block: The YHD hydraulic actuator is equipped with a special modular valve block, which can conduct emergency operation.
  • Special connection mode: Special connection mode is convenient to connect micropower unit.
