CO-10A Air Covering Machine

CO-10A Air Covering Machine
CO-10A Air Covering Machine
CO-10A Air Covering Machine
CO-10A Air Covering Machine
CO-10A Air Covering Machine
Request a Quote

This air covering machine is designed to operate with separate control per spindle, making it suitable for air covering operations for terylene, nylon, spandex, and other materials applied in the production of sporting goods and shoes.

The equipment is outfitted with an online tensioner to ensure the cone is wound with a constant tension to make rewinding easier and ensuring minimal yarn breakage. This also improves yarn quality and production efficiency.

Parameters
TYPE OF WINDING: RANDOM OR PASSIVITY
MECHANICAL SPEED: MAX 900M/MIN (PROCESS SPEED DEPENDING ON PROCESS PARAMETERS)
PACKAGE SHAPE: VERTICAL/ HYPOTENUSE ADJUSTABLE
Traverse Length: 145/225/255mm
Take-Up Package Diameter: 280mm
Package Weight: Up To 4kg
Supply Package Diameter: 320mm
Winding Bobbin: 220-290mm
Applicable Yarn: Polyester, Nylon, Spandex, Polyester Cotton And Polyester Rayon
Layout: Single Side
Number Of Spindles Per Section: 4 Spindles
Number Of Spindles Min./ Max: 4 Spindles/40 Spindles
Gauge: 420mm
Installed Power: 540w
Power Consumption: 220w
Winding Density: Arbitrarily Set
Overall Dimensions(Length X Width X Height Mm) 1662*1005*1750mm
