Welded Fence / Wire Fence / Mesh Fencing

Our welded mesh fences are economical panel systems with longitudinal folds, giving the fence a stronger structure. The fence panels are welded using high quality low carbon steel wire that is surface treated using hot dipped galvanization or electrostatic polyester powder coated.

The wire fences can be installed using SHS tubes, RHS tubes, peach posts round pipe or special-shaped posts. The fence panels are fixed to the post with special clips depending on the post type.

Product Features
Low cost, easy installation
10-Year limited warranty
Galvanized steel components
Suitable to all any location
Panels mounted inside post or on post face
Durable polyester powder coating finish
Welded mesh fencing is widely used for property protection, animal deterrence and many more applications to keep things in or out of certain areas.

Specification
For post
Round post
Size: 48mm, 60mm
Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm
Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

Square post
Size: 50mmx50mm, 60mmx60mm,
Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm
Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

Rectangular post
Size: 40mmx60mm, 40mmx80mm,
Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm
Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

Peach post
Size: 50mmx70mm, 70mmx100mm,
Thickness: 1.2mm, 1.5mm,
Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

I post
Size: 42mmx70mm,
Thickness: 1.2mm, 1.5mm, 2.0mm
Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

For panels
Height: 1.03m, 1.23m, 1.43m, 1.63m, 1.83m, 2.03m, 2.23m, 2.43m.
Width: 2.0m, 2.5m, 2.9m.
Wire thickness: 3.0mm, 3.5mm 4.0mm, 4.5mm, 5.0mm
Spacing between horizontal wire: 100mm, 150mm, 200mm.
Spacing between vertical wire: 50mm, 55mm.
Reforced folds: 100mm, 200mm.

For Colors
Green, white, red, black, yellow etc.
