Horizontal Pin Bead Mill, RTSM-400BJP
Request a Quote
This horizontal pin bead mill is able to achieve micron-level and nano-level final fineness, which means the grinding machine is able to process medium-to-low viscosity and smooth fluid materials. This bead mill features sophisticated rotor design, which involves simulated and actual operation. This is why this horizontal grinding machine can work with excellent grinding efficiency, average-temperature operation and low energy cost. Based on all these advantages, this horizontal pin bead mill is widely used in industries such as pigments, pesticides, fertilizers and ink.
Features
- Certified mechanical design, durable service life for mechanical unit;
- Formula can be easily imported and exported with only pressing the button;
- Slit-type grinding structure, high energy density;
- Reasonable design of material flow channel, high grinding efficiency and uniform particle size;
- Reasonable design of the discharge unit, self-cleaning screen is enabled to deliver long screen service life.
Specifications
- Model No: RTSM-400BJP
- Volume: 400L
- Power: 355kW
- Materials of Inner Grinding Chamber Component: Silicone Carbide
- Materials of Outer Grinding Chamber Component: SS304 Stainless Steel
- Grinding Principle: Pin Type
- Materials of Rotor Component: SS304 Stainless Steel and PU(Polyurethane)
- Max. Line Speed: 14.5m per second
- Materials of Screen Component: SS304 Stainless Steel
- Operation Method: PLC with Touch Screen
- Mechanical Seal: Double-end Container Type
- Pneumatic Diaphragm Pump: 3-inch Pneumatic Diaphragm Pump
