Hydraulic Cargo Elevator
The ASY Hydraulic Cargo Elevator is the ideal partner when you require a quiet, steady, and effective means of lifting products.
With its hydraulic system, this elevator provides smooth, noise-free operation and is perfect for moving large objects in limited areas. Variables in speed control helps you to guarantee a consistent and comfortable ride every time. Our first concern is your safety, hence we have integrated emergency manual valves and overflow valves to maintain your operations free from faults and securely. This elevator is made to fit your requirements regardless of your workplace—a factory, warehouse, station, dock, airport, or supermarket.
When the landing door opens, the cargo cage door remains closed; both doors can open simultaneously to allow access to the cargo cage interior.
| Model | | | | | |
| Rated Payload Capacity | 450kg | 1000kg | 1500kg | 2000kg | 3000kg |
| Hydraulic Cylinder | ⌀95/80-60 ⌀76/60-45 | ⌀95/80-60 ⌀76/60-45 | ⌀110/95-80 ⌀85/70-55 | ⌀110/95-80 ⌀85/70-55 | ⌀110/95-80 ⌀85/70-55 |
| Power of Hydraulic Pump Unit | 4kW | 5.5kW | 5.5kW | 7.5kW | 11kW |
| Rated Lifting Speed | 6m/min | ||||
| Power Supply | 380V(±10%) / 50Hz | ||||
Remarks
1. The proportions of the cabin can be customized to meet your specific needs.
2. The load capacity and lifting speed can be customized to suit your specific operational requirements.
3. External enclosure materials can be tailored to accommodate various surroundings.
