3 Axle Cargo Semi Trailer
Request a Quote
Description:
The 3 axle cargo semi trailer is designed to be light weight, with the entire trailer made using a high strength steel, making it lighter and stronger than other 3 axle cargo semi trailers made of different materials. The trailer weight ranges between 1 and 2 tons.
| Tare Weight | About 7.6T |
| Dimensions (mm) (adjustable) | 13000×2490×2860 |
| Loading Capacity | 40T-60T |
| Axle | 13T/16T, FUWA/BPW /HUAJING Brand. NO.: 2/3 pieces. |
| Rim | 9.00-22.5 |
| Tire | 12.00R22.5, 315/80R22.5 |
| Suspension | Mechanical Suspension (German or American type) or Air Suspension (Chinese brand or BPW brand) |
| Spring leaf | 90mm(width)×13mm(thickness)×10(layer) or 100mm×12mm×12 |
| King pin | JOST brand 2.0 or 3.5 inch bolts type or Welding type |
| Support legs | JOST brand D200T or Chinese brand 28Tons (two speed) |
| Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm; Material is Q345 carbon steel. |
| Side beam | 16mm or 18mm channel steel, material is Q235 carbon steel |
| Side Wall | 600mm-1500mm (customers can choose) |
| Brake chamber | WABCO RE 6 relay valve; T30/30 T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks |
| ABS | Optional |
| Twist Locks | Four, eight or twelve pieces (lifting type or twist screw type), optional |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Painting | The complete chassis undergoes a sandblasting process to remove any rust. A single coat of a corrosion prevention primer, then 2 coats of final paint |
Sanxing has been manufacturing heavy duty vehicles and special vehicles since 1994. Besides the 3 axle cargo semi trailer, we offer a wide range of aluminum alloy tank trailer, carbon steel tank trailer, flatbed trailer, cargo semi-trailer and so on. From the raw material selection to manufacturing process, we have rich experience and offer high quality 3 axle cargo semi-trailers and other special transport vehicles with custom solutions.
