Light Duty Vertical Reciprocating Conveyor
Vertical lift system for transferring materials between several levels
Light duty vertical reciprocating conveyor is used for high-speed reciprocating transportation of smaller, lightweight pallet goods between several levels. It serves as a more convenient and efficient alternative to freight elevators in industries such as warehousing, distribution, and automated production lines.
The light-duty reciprocating vertical lift system consists of top drive components, main frame, cargo platform (carrying conveyor), counterweight components, external conveyor lines, and various accessories. The most important drive components include drive wheels, driven wheels, lifting chains/synchronous belts, drive motors, and drive frames. The specifications of the drive sprockets and lifting chains are typically customized based on the specific requirements of the project.
Light duty vertical reciprocating conveyor is used for transferring various materials carried on pallets.
EV battery, automated warehouse logistics, tobacco and alcohol industry, e-commerce retail, pharmaceuticals and food, automotive and construction materials, etc.
Light duty vertical reciprocating conveyor has a small load capacity, small space, smooth lifting operation, higher vertical conveying efficiency, and a wide range of vertical transportation heights.
- Four-column frame.
- Equipped with a counterweight module.
- Optional integration with built-in conveyor.
- Four-chain lifting mechanism.
- Power unit located at the top.
- Enclosure using structural mesh panels.
- Utilizes elevator guide rails.
| Product Information | ||
| Basic Information | Load Capacity | ≤600kg |
| Conveying Speed | 12, 16, 18, 20m/min | |
| Lifting Speed | 20m/mim~90m/min | |
| Temperature | 5℃ to 45℃ | |
| Relative Humidity | ≤90% (No condensing) | |
| Equipment Index | Length mm | 1800≤L≤3000 |
| Width mm | 2100≤L≤4100 | |
| Lowest Infeed/Outfeed Position | 500mm | |
| Drive Mode (Lifting) | Drive Motor | Gear motor |
| Motor Power | Depending on the project | |
| Motor Voltage | 380V | |
| Brake Voltage | 220V | |
| Drive Method | Chain/Timing belt | |
| Installation | Ground Installation | Expansion bolts |
| Ground Flatness | Level ground, error ≤5° | |
| Height Adjustment | ±10mm | |
