Halogen-free Heat Shrink Marker Sleeve Manufacturer

Halogen-free Heat Shrink Marker Sleeve

Request a Quote

View All: http://heatshrink-tubing.com/3-3-halogen-free-heat-shrink-marker-sleeve.html

Halogen-free Heat Shrink Marker Sleeve, RSFR

Model: RSFR

RSFR-M halogen-free heat shrink marker sleeve is a flattened heat-shrinkable tubing designed for wiring harness identification. This heat shrink marker sleeve is ideal for applications where limited fire hazard characteristics are necessary. The RSFR-M halogen-free heat shrink marker sleeve is printable using thermal transfer printer, and the identification marks are durable and can remain legible even when exposed to abrasion, aggressive cleaning solvents and industrial fluids.

Standard

SAE-AS 81531, MIL-STD-202F/Method 215J, UL224, RoHS etc.

Features

Material: fabricated from irradiated, thermally stabilized, flame retarded, modified polyolefin compound without halogens or cadmium in formulation
Application: commercial, industrial, etc.
Operating temperature range: -40℃～ 125℃
Minimum recovery temperature: 85℃
Maximum storage temperature: 50℃
Shrink ratio: 2:1, 3:1
Color: white, yellow, other colors are available upon request
Printing: single sided printing or double sided printing
Supplied format: ladder-style or continuous sleeve
Recommended printer: thermal transfer printer
Recommended ribbon: N85 resin ribbon, black, 100mm(width)×300m(length)

Dimensions

Shrink ratio-2X

Order Code	As Supplied (mm)			As Supplied (mm)
Order Code	ID (D)	Flatten Width (W2)	Double Wall Thickness	ID (d)	Single Wall Thickness
AMS-M-2X-1.6	2.00±0.20	3.7±0.3	0.48±0.10	≤0.79	0.45±0.06
AMS-M-2X-2.4	2.79±0.20	5.0±0.3	0.48±0.10	≤1.18	0.49±0.06
AMS-M-2X-3.2	3.64±0.23	6.3±0.4	0.48±0.10	≤1.59	0.51±0.06
AMS-M-2X-4.8	5.26±0.25	8.9±0.4	0.49±0.10	≤2.36	0.54±0.06
AMS-M-2X-6.4	6.92±0.28	11.5±0.4	0.50±0.10	≤3.18	0.56±0.06
AMS-M-2X-9.5	10.2±0.32	16.7±0.5	0.51±0.11	≤4.75	0.59±0.06
AMS-M-2X-12.7	13.5±0.36	21.8±0.6	0.52±0.11	≤6.35	0.60±0.07
AMS-M-2X-19-	20.1±0.40	32.2±0.6	0.53±0.11	≤9.53	0.62±0.07
AMS-M-2X-25-	26.7±0.45	42.5±0.7	0.55±0.12	≤12.7	0.63±0.07
AMS-M-2X-38-	39.8±0.51	63.2±0.8	0.57±0.12	≤19.1	0.64±0.07
AMS-M-2X-51-	53.0±0.56	83.9±0.9	0.58±0.13	≤25.4	0.64±0.08
AMS-M-2X-76-	79.4±0.56	125.3±1.0	0.59±0.13	≤38.1	0.64±0.09

Shrink ratio-3X

Order Code	As Supplied (mm)			As Supplied (mm)
Order Code	ID (D)	Flatten Width (W2)	Double Wall Thickness	ID (d)	Single Wall Thickness
AMS-M-3X-1.6-	2.00±0.20	3.7±0.3	0.47±0.10	≤0.53	0.52±0.06
AMS-M-3X-2.4-	2.79±0.20	5.0±0.3	0.47±0.10	≤0.79	0.57±0.06
AMS-M-3X-3.2-	3.64±0.23	6.3±0.4	0.48±0.10	≤1.06	0.61±0.06
AMS-M-3X-4.8-	5.26±0.25	8.9±0.4	0.49±0.10	≤1.59	0.67±0.06
AMS-M-3X-6.4-	6.92±0.28	11.5±0.4	0.50±0.10	≤2.36	0.71±0.06
AMS-M-3X-9.5-	10.2±0.32	16.7±0.5	0.52±0.11	≤3.18	0.77±0.06
AMS-M-3X-12.7	13.5±0.36	21.8±0.6	0.53±0.11	≤4.75	0.80±0.07
AMS-M-3X-19-	20.1±0.40	32.2±0.6	0.55±0.11	≤6.35	0.84±0.07
AMS-M-3X-25-	26.7±0.45	42.5±0.7	0.56±0.12	≤8.47	0.86±0.07
AMS-M-3X-38-	39.8±0.51	63.2±0.8	0.57±0.12	≤12.9	0.89±0.07
AMS-M-3X-51-	53.0±0.56	83.9±0.9	0.57±0.1	≤17.2	0.90±0.08
AMS-M-3X-76-	79.4±0.56	125.3±1.0	0.57±0.13	≤25.8	0.92±0.09
