Non Heat Shrink PE Tubing
Request a Quote
Model: CB-300(PE)/ 600(PE)
Material: Crosslinked modified polyolefin resin
Application
Non heat shrink PE tubing is an upgrade substitute product for non-shrink PVC tubing since its main material, crosslinked modified polyolefin resin is a halogen-free environmentally friendly material which meets the requirements of RoHS, Reach and SONY environmental protection standards. Non heat shrink PE tubing iswidely used in electronic components, home appliances, automobiles, machinery, toys, sporting goods and other fields.
| Size | AS supplied | Wall thickness for 300V | Wall thickness for 600V |
| Bφ0.9 | 0.95±0.05 | 0.38±0.05 | 0.5±0.06 |
| Bφ1.4 | 1.45±0.05 | 0.38±0.05 | 0.62±0.06 |
| Bφ2.0 | 2.05±0.05 | 0.38±0.05 | 0.62±0.06 |
| Bφ2.5 | 2.55±0.05 | 0.38±0.05 | 0.62±0.06 |
| Bφ3.0 | 3.1±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ3.4 | 3.5±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ4.0 | 4.1±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ4.8 | 4.9±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ5.8 | 5.9±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ6.3 | 6.4±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ6.8 | 6.9±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ7.3 | 7.4±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ7.8 | 7.9±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ9.7 | 8.9±0.1 | 0.5±0.06 | 0.62±0.06 |
| Bφ10.6 | 9.85±0.2 | 0.5±0.06 | 0.62±0.06 |
| Bφ11.6 | 10.8±0.2 | 0.5±0.06 | 0.62±0.06 |
| Bφ12.6 | 11.8±0.2 | 0.62±0.06 | 0.75±0.06 |
| Bφ13.6 | 12.8±0.2 | 0.62±0.06 | 0.75±0.06 |
| Bφ14.6 | 13.8±0.2 | 0.62±0.06 | 0.75±0.06 |
| Bφ15.6 | 14.8±0.2 | 0.62±0.06 | 0.75±0.06 |
| Item | Specifications | |
| Temperature Rating (℃) | 125 | |
| Longitudinal Change | ≤±5% | |
| Tensile Strength (MPa) | ≥10.4 | |
| Ultimate Elongation Ratio (%) | ≥100 | |
| Aging in Circulating-air Oven | 136.0±1.0℃, 168hrs | |
| After aging | Tensile Strength (MPa) | ≥7.3 |
| Ultimate Elongation Ratio (%) | ≥100 | |
| Potential Rating (V) | 300V, 600V | |
| Volume Resistance (Ω cm) | ≥1010 | |
| Dielectric Strength (V) | 2500 (60s),No breakdown | |
| Corrosion of Bare Copper | No corrosion | |
| Heat Shock | No cracking | |
| Cold Bend | No cracking | |
- Suitable substitute for non-shrink PVC tubing, halogen-free and environmentally friendly, meets the standards of "RoHS" and "Sony", UL CUL certification.
- Can effectively replace PVC tubing. (except clear PVC)
- Low smoke and resistant to flame, meets the requirements of UL224 VW-1 and JQA F-mark in Japan.
